Fortin Key-Override-All Guide Rapide

LED Module Diagnostics :
On: Activated.
OFF: Not activated.
Flash: Not programmed.
Purple/White
Yellow/Black
Blue
Green
Yellow
White
1
Connector 1 (Black - 4 pins):
Determin the type of installation:
INSTALLATION
DATA-LINK
Front view of the module
INSTALLATION
WITHOUT
DATA-LINK
Cut off one plug of the Data-Link connector, connect the red wire to +12V and the black wire to ground.
20 pin connector
10 9 8 7 6 5 4 3 1 10 9
18 17 16 15 14 13 12 11
Located under dash,
left side of steering
column.
CUT
Brown/White or Pink
(Security light)
Connector 4 (White - 4 pins ):
FLASH LINK UPDATER
Connect with the for
web update.
Connect wire to Remote-Starter/Alarm
Copyright © 2008, FORTIN AUTO RADIO INC ALL RIGHTS RESERVED
Hyundai XG350
White connector located under dash,
right side of diagnostic connector (OBDII)
Data
N.c.
2
(-) While running
N.c.
Ignition
N.c.
Rede
conn.
Data-Link connector
Black
WITH
Blue
White
Red +12V
Ground
Black
Blue
White
8 7 6 5 4 3 1
18 17 16 15 14 13 12 11
Relay 1a
White/Black
3
Relay 1b
Pink/Black
N.c.
conn.
N.c.
4
Web Update connector*
conn.
* Connector not supplied
Connect wire to vehicle
Technical support:
TEL: 514-255-HELP (4357)
FAX: 514-255-1367
Web: www.ifar.ca
2002-2005
GREEN Pin 8 (DATA)
1 2 3 4
5 6 7 8 9 10
Starter or alarm
Port Data Link
conn.
White
Pink
Back view of the module
OUTPUT INPUT
Neither the manufacturer or distributor of this module is
responsible of damages of any kind indirectly or directly
caused by this module, except for the replacement of this
module in case of manufacturing defects. This module must
be install by qualified technician. This instruction guide may
change without notice. Visit www.ifar.ca to get latest version.
KEY-OVERRIDE-ALL
WEB
Made in Canada - Rev. A - 02 / 07 / 2008
UPDATE
W e b s i t e
ENCRYPTED TRANSPONDER BYPASS MODULE ( Self Learning )
1
Make the connections to the vehicle:
Connector 1 (Black):
1.A
Determin the type of installation:
- INSTALLATION WITH DATA-LINK
- INSTALLATION WITHOUT
Connector 2 (White): Make the connections
1.B
Connector 3 (White): Make the connections
Press and hold the programming button.
2
Insert connector 1
Insert connector 2
If the LED is flashing at this point the module is
3
already programmed and can't be programmed
again. (To prevent malicious use this module can
be programmed in only one vehicle.)
While holding the programming button.
4
Insert connector 3
5
Release the programming button
when the LED turns ON.
Press 1 time on the programming button.
6 The LED turns OFF and turns ON.
7
Press 2 more times
button and the LED will flash twice.
8
Turn the Ignition to the ON
If the LED flashes 10 times, the
module is programmed.
9
If the LED stays ON, verify your connections
and repeat from step 1.
10 Turn the Ignition key to the OFF position.
Remove the key and start the vehicle using the
11 remote starter to ensure functionality.
: h t t p : / / w w w . i f a r . c a
DATA-LINK
.
.
.
on the programming
position.
