Stage 3 Assembly - Evenflo ExerSaucer Triple Fun Manuel D'instructions

Stage 3 Assembly

C
C
A
A
A
A
7. Connect tray halves C to form activity table.
Note: Make sure the tray halves lock securely.
8. Rotate leg assemblies A fully counterclockwise, (the
direction of the arrow) until they lock into the position
shown. Make sure that all four leg locks
I
properly into the upper leg crown , as shown
above. Also, make sure the ends of all four leg
H
locks are sticking out past the edge of the tray,
as shown.
IMPORTANT: DO NOT use this activity table unless
the legs have locked into place!
H
I
H
H
12
H are locked
E
9. Install the small end cap
the locking tabs
opening, as shown.
F
G
F
10. Turn table over and install the large end cap
as shown. Make sure both end caps
locked into place.
11. Install toys on activity table. If desired, adjust table to
the appropriate height (page 8) for your child.
Note: Always make sure that all four legs are
adjusted to the same height.
IMPORTANT: NEVER use Stage 3 without end caps!
F
13
Stage 3 Assembly
F , as shown. Make sure
G
have locked over the edge of the
E ,
E F
and are
