Rear Panel

For details on the use of the connectors, see pages 11
and 12.
VIDEO IN connectors 1,2
(phono)
S VIDEO IN connectors 1,2
(4-pin mini DIN)
AC IN connector
AC IN
AC OUT receptacle (NTSC model only)
AUDIO R IN connectors 1,2 (phono)
AUDIO L IN connectors 1,2 (phono)
IN
VIDEO 1 VIDEO 2
S VIDEO
AC OUT
AC 120V 60Hz
VIDEO
MAX 2.5A
UNSWITCHED
L
AUDIO
R
VIDEO OUT 2 connector
(BNC type)
VIDEO OUT 1 connector
(phono)
S VIDEO OUT connector
(4-pin mini DIN)
OUT
S VIDEO
VIDEO 1
2
L
AUDIO
RS-232C
R
AUDIO R OUT
connector (phono)
AUDIO L OUT
connector (phono)
RS-232C connector
(D-sub 9-pin, male)
9
