ASSEMBLY INSTRUCTIONS
READ THESE INSTRUCTIONS BEFORE STARTING;
FOLLOW THE ASSEMBLY PROCEDURES CAREFULLY
LETTER
DESCRIPTION
CODE
§ Back Loop
A
§
Base Loop
B
§ Platform
C
§
A
SNAP BUTTONS ON
BACK OF LOOP
§
B
Thank you for purchasing this Safco
product.
Due to continual upgrading of our
products, photographs or illustrations
may not reflect actual (exact)
appearance of product.
5124-37: 1 of 2; Rev. 2; 9/00
Stand-Alone Footrest
PARTS LIST
QTY. PART NO.
1 5124-02
1 5124-03
1 5124-01
HOLES ON
FRONT OF LOOP
WIRE PRONGS
§
C
This product functions as a high-range, heavy-duty footrest. It
relaxes tired feet, and provides added comfort and relief by
alleviating pressure on thighs while accommodating high work
surfaces. A large base reduces the chance of tipping. The non-
skid surface keeps feet from slipping. Height is adjustable over
an 9-1/2" range.
1
Insert the § A Back Loop into the sockets in the
Base Loop, with the snap buttons on the back loop
facing outward. Push back loop down until the snap
buttons snap into the holes in the sockets of the base
loop.
2
Grasp the § C Platform by the sides, with the wire
prongs away from you. Tilt the platform front up, and
line up the wire prongs on the platform back with the
desired set of holes in the back loop.
3
Insert the prongs into the holes, and tilt the platform
down until its back surface rests flat against the back
loop.
To change the footrest height, lift the front of the
platform until the prongs can be disengaged, then
reinsert into new position as before.
GENERAL SAFETY INSTRUCTIONS
●This product is designed as a footrest, not a stepstool or chair;
do not sit or stand on the platform.
●This product must be on level surface to ensure proper stability.
●Only use this product when fully assembled.
●Never use this product if it does not perform according to this
sheet.
●lmmediately report any problems to Safco and always give the
manufacturer's date code information from the carton.
NUMBER
ASSEMBLED UNIT
Model 5124
MODEL
5124
§ B
