Front panel

1
2
3
30 30
YPbPr CC MTS VGA
DTV TV AV HDMI
STRENGTH
CH LIST EPG FAV
TV
DISPLAY
S.M
VOL CH
P.M
1. Remote control sensor.
2. Indicator LED:
RED STAND BY.
3. Key board.

REAR Connections

All the terminals are (from left to right):
OPTICAL, VIDEO,

AUDIO INPUT

SIDE Connections

HDMI1(ARC) HDMI2
All the terminals are (from left to right):
HDMI1(ARC), HDMI2, HDMI3, HEADPHONE,
Note: When HDMI has an input signal coming from a DVI source then the audio input signal must be
connected to the PC audio input.
All manuals and user guides at all-guides.com
.
HDMI3 HEADPHONE
Panel keys
1. Short press to turn on the TV.
2. When the TV is on, short press the button to
display the input list.
3. When the TV is on, press and hold the button to
power off the TV.
OPTICAL
USB Media Player
USB Media Player , RF.
