ReVent RVSH90 Guide D'installation page 16

3.) Attach FAN to ceiling joists with BRACKETS using ROUNDHEAD WOOD
SCREWS, then install the sheetrock for your ceiling.
conduit
SHORT
BRACKET
(can be
cut down)
framing joist
BRACKET
SECURING
4.) Attach conduit with wiring to FAN.
framing joist
5.) Attach DAMPER to ducting.
framing joist
SHORT
BRACKET
#8 x / "
3
8
SCREW
Qty:3
FAN
FAN
ducting
LONG
BRACKET
DAMPER
DAMPER
Attach DAMPER to
ducting with duct tape
15
FAN
framing joist
ROUNDHEAD
WOOD SCREW
Qty:6
(use 2 per
bracket)
conduit
ducting
conduit
