3 Using the Source/Load Functions
Power - Lets you enter a power value with the numeric keys. Press Enter to enter the value.
Range - Sets the power range. The value that you enter must be the highest value in Watts that you
expect to source. The following ranges can be selected:
High power range
Low power range
Refer to Current Priority Mode
From the remote interface:
To specify the load priority mode:
FUNC VOLT,(@1)
FUNC CURR,(@1)
FUNC RES,(@1)
FUNC POW,(@1)
To set the voltage to 10 V, the current to 5 A, the resistance to 100 Ω, and power to 50 W:
VOLT 10,(@1)
CURR 5,(@1)
RES 100,(@1)
POW 50,(@1)
Optionally, set a current limit value of 5 A while in voltage priority mode:
CURR:LIM 5,(@1)
To select a lower current, power, or resistance range, program a value that falls within the range:
CURR:RANG 5,(@1)
RES:RANG 50,(@1)
POW:RANG 5,(@1)
To short the input terminals:
OUTP:SHOR ON,(@1:2)
96
N6791A
from 0.3 W to 100 W
from 0.04 W to 10 W
for descriptions of the Under Voltage Inhibit and Enable short controls.
N6792A
from 0.5 W to 200 W
from 0.1 W to 20 W
