2. If a trouble is detected on a zone, the zone is identified along with the message
TROUBLE. If this is a temperature or dry contact zone with an end of line resistor, the
nature of the trouble is also displayed, i.e. SHORT-CIRCUIT or OPEN CIRCUIT. This
message continues to be scrolled as long as the user has not erased the trouble using
the Trouble key even if the problem has been fixed.
ZONE#45
SMALL BREEDER
ZONE#45
TROUBLE
ZONE#45
SHORT CIRCUIT
3. If a zone has an alarm, it is identified along with the message ALARM. If this is an
activated temperature zone, the current temperature is displayed, along with the high
(H) and low (L) set points, critical temperature (C) and the minimum and maximum
temperature values (when appropriate).
ZONE#45
SMALL BREEDER
ZONE#45
87.5F ALARM
ZONE#45
L50, H85, C95
ZONE#45
MIN 65 MAX 78
4. In the case of activated temperature zones, the system displays the zone label,
current temperature, high (H) and low (L) set points, critical temperature (C) and the
minimum and maximum temperature values (when appropriate).
ZONE#45
SMALL BREEDER
ZONE#45
70.5F
