Changing The Battery - Armacost Lighting RibbonFlex PRO+ Mode D'emploi

Pairing multiple kits
The remote in each kit comes paired with the tape light. For larger installations,
multiple kits can be paired together for control by a single remote.
PAIRING
Unplug the power supply for the kit that is to be paired.
■
Wait 5 seconds
Restore power to the power supply, then within 10 seconds press and
■
hold the power and brightness down buttons on the remote at the
same time
The lights will flash to indicate a successful pairing This kit will now
■
operate with the remote used in this procedure. Repeat as desired
with other kits and remotes.
Each remote uniquely
paired to a kit
TO RETURN TO SINGLE-REMOTE OPERATION
For each kit, perform the following steps using a unique remote:
Unplug the power supply for the kit that is to be returned to single-
■
remote operation.
Restore power to the power supply, then within 10 seconds press and
■
hold the power and brightness down buttons at the same time. (The
lights will flash to indicate the signal has been received.)
Perform the two steps above a second time to complete the process
■
This kit will now operate only using the remote used in this procedure.
Repeat as desired with other kits and remotes.

Changing the battery

To replace the battery, slide the cover up
■
and remove the old battery.
Always purchase the correct size and grade
■
of battery that is most suitable for the
intended use.
Ensure the battery is installed correctly with
■
regard to polarity (+ and –).
Remove battery from the equipment when
■
it is not being used for an extended period
of time.
Remove used batteries promptly.
■
WARNING: The remote contains a CR2032
■
DC 3V button battery. If swallowed, it could
cause severe injury or death within 2 hours.
Seek medical attention immediately.
4
One remote paired
to multiple kits
CARE AND CLEANING
To clean the light, use a clean dry or slightly damp cloth.
■
Do not use cleaners with chemicals, solvents or harsh abrasives
■
as damage to the light strip may occur.
TROUBLESHOOTING
The LED strip will not light.
The power supply does not have power. Make sure the plug is fully
■
inserted into a live 120-volt outlet. Check connections and circuit
breaker if direct wiring.
The power supply output cable is not properly secured. Make sure that the
■
DC output cable is wired securely to the output of the power supply.
The polarity is incorrect. Check that the orientation of the input and
■
output match the markings on the case.
Batteries in the remote are dead, improperly installed, or the battery
■
protector has not been removed. Make sure the battery protective strip
is removed. Check that the orientation and type of battery are correct
and that the battery is not depleted.
The remote is too far from the receiver. The remote can operate up
■
to 50 feet in optimal conditions, but each installation has unique
variables that may affect range.
Only part of the LED strip lights.
A connection point is faulty. Check for secure connections at the point
■
that is not lit. Confirm that polarity is the same between the lit and
unlit segments.
The fuse blows or a circuit breaker trips when the light is turned on.
A wire is exposed. Discontinue use of the lamp. Unplug the unit from
■
the wall. Contact a qualified electrician.
FCC STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
CAUTION: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
■
Increase the separation between the equipment and receiver.
■
Connect the equipment into an outlet on a circuit different from that
■
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
■
CUSTOMER SUPPORT
Email: support@armacostlighting.com | Phone: 410-354-6000
Monday–Friday, 9 a.m.–5 p.m., EST
Baltimore, Maryland
armacostlighting.com
© 2021 Armacost Lighting. All rights reserved.
211001
