Introduction
Purpose
This field service bulletin describes the steps necessary to replace the power switch in the Powermax45. Which kit you
will need depends on the model of Powermax45 you have. Use kit number 228266 to replace the power switch on a
200–240 V CSA or 230V CE system. Use kit number 228288 to replace the power switch on a 400V CE or 480 V
CSA system.
Tools and materials needed
 #2 Phillips screwdriver
228266 Kit contents
Part number
005619
075721
228288 Kit contents
Part number
005618
075845
Powermax45 Field Service Bulletin 805880 Revision 3
All manuals and user guides at all-guides.com
Disconnect electrical power before performing any maintenance. See the
Safety and Compliance Manual for more safety precautions.
Description
Switch: 3P 240VAC 50A Rocker w/TC
Machine Screw: M3 X 0.5 X 10-7 PH PAN 2SEM S/Z/TRI BLK
Description
Switch: 3P 600VAC 25A
Plastite Screw: #8 X 5/8 PHILLIP FLAT BLK ZNC
Powermax45 Power Switch Replacement Kit
DANGER!
ELECTRIC SHOCK CAN KILL
Quantity
1
4
Quantity
1
4
1
