Operating Instructions
MaxLite HL Linear High Bay Generation 3
®
Optional Accessories Installation Instructions
Wire-Guard Installation (HL3-WG%):
MaxLite Part #:
HL3-WGW1
HL3-WGW2
HL3-WGW3
HL3-WGW4
Note: HL3-WGWSx models must be used when a sensor node needs to be installed.
1. Locate the screw holes on the fixture surface. There should be 5 screw holes for the smaller housing size (150W
or less) and 6 screw holes for the larger housing size.
2. Attach the metal clips around the wire guard. Ensure that the clips are spaced evenly so that the screws can be
used to fix them.
3. Use the M4*6 screws to fix the clips on the fixture housing. Ensure that the wire guard is firmly attached.
© Copyright 2022. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com
MaxLite Part #:
HL3-WGWS1
HL3-WGWS2
HL3-WGWS3
HL3-WGWS4
HL3 Series
Page: 5
REV: 11/02/22
