Inserting the accumulator unit

Please follow carefully the steps below for insert-
ing the accumulator unit to the QuikRead go in-
strument.
1. Turn off the instrument (if on).
2. Unplug the power supply cable.
3. Turn the instrument onto its side on a table.
4. Open the accumulator unit cover.
5. Attach the accumulator connector to the ac-
cumulator unit.
6. Press the accumulator unit into its place and
ensure that it is placed properly.
7. Close the accumulator unit cover.
8. Turn the instrument back to a standing
position.
10
GETTING STARTED
1
Picture 8
1. Accumulator unit cover
2. Accumulator connector
3. Accumulator unit
4. Clock battery
2 4
3
