USER MANUAL
COMPONENTS
BAT 24V BATTERIES
CH BATTERY CHARGER
EB1 CONTROL PANEL BOARD
EB2 USB CHARGING ELECTRONIC BOARD
EB3 DRIVE ELECTRONIC BOARD
RL1 BRUSH MOEOR ELECTROM SWITCH
RL2 VACUUM MOEOR ELECTROM SWITCH
RL3 DRIVE SYSTEM ELECTROM SWITCH
YV WATER ELECTROVALVE
F1 CONTROL PANEL BOARD FUSE
F2 BRUSH MOTOR CIRCUIT BREAKER
F3 VACUUM MOTOR CIRCUIT BREAKER
F4 DRIVE SYSTEM CIRCUIT BREAKER
F5 BRUSH RELEASE FUSE
KA BRAKE
COMPONENTS
M1 BRUSH MOTOR
M2 VACUUM MOTOR
M3 DRIVE MOTOR
SW1 EMERGENCY-STOP SWITCH
SW2 KEY SWITCH
SW3 CLEAN WATER LEVEL SWITCH
SW4 VACUUM MOTOR SWITCH
SW5 OPTIONAL MODE SWITCH
SW6-A OPTIONAL REVERSE SWITCH
SW6-B OPTIONAL REVERSE SWITCH
SW7 SEAT SWITCH
SQ FOOT THROTTLE
SPK 12VDC BUZZER
VR SPEED POTENTIOMETER
8
WIRE ROD
RD1 RED/6AWG
RD2 RED/10AWG
RD3 RED/18AWG
RD4 RED/20AWG
RD/BK RED/BLACK/20AWG
BK1 BLACK/6AWG
BK2 BLACK/10AWG
BK3 BLACK/12AWG
BK4 BLACK/14AWG
BK5 BLACK/18AWG
BN1 BROWN/14AWG
BN2 BROWN/20AWG
ENGLISH
WIRE ROD
BN/BK BROWN/BLACK / 20AWG
BU1 BLUE/18AWG
BU2 BLUE/20AWG
BU/BK BLUE/BLACK/20 AWG
GN GREEN/20AWG
GN/BK GREEN/BLACK / 20AWG
GY GRAY/20AWG
PU PURPLE/20AWG
OR ORANGE/20AWG
YE YELLOW/20AWG
WH1 WHITE/12 AWG
WH2 WHITE/20AWG
