4 Product description
4.1 Overview
standard version
A. Vent valve
B. Stroke valve
C. Heating circuit manifold line (depends on
version)
D. Flow meter
E. End cap
F. Flow valve
G. Boiler filling and drain valve KFE
H. Thermometer
Product description
A
H
G
F
ECOLLECTRMX
B
C
Accessories (optional)
1. Actuator
EN
1
D
E
