A.
B.
H.
C.
D.
I.
J.
E.
K.
L.
F.
G.
CAPABILITIES
Will shred: Paper, credit cards, CD/DVDs, staples and small paper clips
Will not shred: Continuous forms, adhesive labels, transparencies, newspaper,
cardboard, large paper clips, laminates or plastic other than noted above
Paper shred size:
Cross-Cut ................................................................ 5/32 in. x 2 in. (4mm x 50mm)
IMPORTANT SAFETY INSTRUCTIONS — Read Before Using!
• Keep away from children and pets. Keep hands away from paper entry. Always
set to off or unplug when not in use.
• Keep foreign objects – gloves, jewelry, clothing, hair, etc. – away from shredder
openings. If object enters top opening, switch to Reverse (R) to back out object.
• Never use aerosol products, petroleum based lubricants or other flammable
products on or near shredder. Do not use canned air on shredder.
• Do not use if damaged or defective. Do not disassemble shredder.
Do not place near or over heat source or water.
• Operation, maintenance, and service requirements are covered in the instruction
manual. Read the entire instruction manual before operating shredders.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment
has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
2
DS-2_406565_3L_NA_022212.indd 2-7
DS-2_406565_3L_NA_022212.indd 2-7
All manuals and user guides at all-guides.com
ENGLISH
Model DS-2
KEY
A. Shredder head
E. Waste opening
J. SafeSense
®
override switch
B. SafeSense
®
F. Bin full indicator
Technology (yellow)
G. Basket
C. Paper entry
H. Disconnect power switch
Active
Not Active
D. See safety
1. OFF
K. Grips
instructions below
2. ON
L. Control Switch
I. Handle
1. Auto-On (green)
R 2. Reverse
3. Overheat (red)
Maximum:
Sheets per pass ....................................................................................................8*
Cards per pass ....................................................................................................... 1
Paper width .........................................................................................9 in./229mm
*20 lb., 8.5 in. x11 in. paper at 120v, 60 Hz, 3.5Amps; heavier paper, humidity or other than
rated voltage may reduce capacity. Recommended maximum daily usage rates: 80 sheets,
5 credit cards;
8 sheets per pass.
Fellowes SafeSense
®
shredders are designed to be operated in home and office
environments ranging between 50 – 80 degrees Fahrenheit (10 – 26 degrees Celsius) and
40 – 80% relative humidity.
• This shredder has a Disconnect Power Switch (H) that must be in the ON ( )
position to operate shredder. In case of emergency, move switch to OFF (O) position.
This action will stop shredder immediately.
• Avoid touching exposed cutting blades under shredder head.
• Shredder must be plugged into a properly grounded wall outlet or socket of the
voltage and amperage designated on the label. The grounded outlet or socket
must be installed near the equipment and easily accessible. Energy converters,
transformers, or extension cords should not be used with this product.
• FIRE HAZARD – Do NOT shred greeting cards with sound chips or batteries.
• For indoor use only.
• Unplug shredder before cleaning or servicing.
FUNCIONAMIENTO BÁSICO DE LA TRITURADORA
PAPEL/TARJETA
Funcionamiento continuo:
2
1
Hasta 4 minutos como máximo
NOTA: la destructora funciona brevemente
después de cada pasada para limpiar la
entrada. El funcionamiento continuo durante
Apáguela
Presione Encendido
más de 4 minutos activará el período de
automático ( )
enfriamiento de 20 minutos.
CARACTERÍSTICAS AVANZADAS DEL PRODUCTO
OPERACIÓN DE LA TECNOLOGÍA SAFESENSE
®
Detiene automáticamente la trituración cuando las manos tocan la abertura para papel.
CONFIGURACIÓN Y PRUEBA
2
3
1
DS-2
Toque el área de prueba y
SafeSense
®
está activa y
Coloque la trituradora en la
espere a que el indicador
funciona correctamente
posición de ENCENDIDO ( )
de SafeSense
®
se encienda
para activar SafeSense
®
MANTENIMIENTO BÁSICO DEL PRODUCTO
REALICE EL SIGUIENTE PROCEDIMIENTO DE ACEITADO Y REPÍTALO DOS VECES
ACEITADO DE LA TRITURADORA
1
Todas las trituradoras de corte cruzado necesitan aceite para
brindar un máximo rendimiento. Si no se aceita la trituradora,
se puede reducir la capacidad de hojas, pueden aparecer ruidos
molestos al triturar y, en última instancia, es posible que deje de
Apague la trituradora
funcionar. Para evitar estos problemas, le recomendamos aceitar
la trituradora cada vez que vacíe la papelera.
*Use sólo aceite vegetal que no sea en aerosol en un contenedor de boquilla larga, como el Fellowes 35250
PRECAUCIÓN
SOLUCIÓN DE PROBLEMAS
Indicador de sobrecalentamiento: Cuando el Indicador de sobrecalentamiento está encendido, significa que la trituradora ha
sobrepasado la temperatura de operación y se debe enfriar. Este indicador permanecerá iluminado y la trituradora no funcionará
durante el transcurso del período de recuperación. En la sección Funcionamiento básico de la trituradora encontrará más información
sobre la operación continua y el tiempo de recuperación de esta máquina.
PAPEL ATASCADO
1
2
3
4
Presione y mantenga
Alterne lentamente hacia delante y hacia atrás
Apague y
presionado Retroceso
desenchúfela
(R) durante 2 ó 3
segundos
5
6
3
4
o
Introduzca la
Introduzca el papel
Mantenga la tarjeta de
Apáguela
crédito sobre el borde
tarjeta en la
en la entrada y suelte
entrada y suelte
2
3
* Aplique aceite en la
Presione Retroceso (R)
entrada
durante 2 ó 3 segundos
5
6
Hale suavemente del
Presione y mantenga
papel sin cortar de
presionado Retroceso (R)
la entrada del papel.
Enchúfela.
7
