LERBAKKEN 10, 8410 RØNDE DENMARK

For safe installation of 9107B the following must be observed. The module shall only be

Installed by qualified personnel who are familiar with the national and international laws,

directives and standards that apply to this area.

Year of manufacture can be taken from the first two digits in the serial number.

For Installation in Zone 2 the following must be observed.

The 4501 programming module is to be used solely with PRelectronics modules. It is

important that the module is undamaged and has not been altered or modified in any way.

Only 4501 modules free of dust and moisture shall be installed.

9107BA:

9107BB:

Supply terminal (31,32)

Voltage:

Status Relay. terminal (33,34)

Voltage max:

Power max:

Current max:

Zone 2 installation:

Voltage max:

Power max:

Current max:

Installation notes:

In Class I, Division 2 installations, the subject equipment shall be mounted within a too-secured enclosure

which is capable of accepting one or more of the Class I, Division 2 wiring methods specified in the National

Electrical Code (ANSI/NFPA 70) or Canadian Electrical Code (C22.1).

In Class I, Zone 2 installations, the subject equipment shall be mounted within a tool secured enclosure which

is capable of accepting one or more of the Class I, Zone 2 wiring methods specified in the National Electrical

Code (ANSI/NFPA 70) or Canadian Electrical Code (C22.1). Where installed in outdoor or potentially wet

locations, the enclosure shall, at a minimum, meet the requirements of IP54.

Install in environments rated Pollution Degree 2 or better; overvoltage category I or II.

The equipment shall be installed in an enclosure with a minimum ingress protection rating of IP54 unless the

apparatus is intended to be afforded an equivalent degree of protection by location.

The module is galvanically isolated and does not require grounding.

Use 60 / 75 ºC copper conductors with wire size AWG: (26-14)

Warning: Substitution of components may impair intrinsic safety.

Revision date:

2019-04-04
