STEERING TRIM

The vehicle should go straight without turning the steering wheel. If not, press the Steering Trim knob above the steering
wheel in the direction needed for the vehicle to go straight.
Steering Trim
THROTTLE/BRAKE TRIM
Normally you do not need to adjust anything here, because the neutral point is stored automatically during the ESC
setting. But if the motor turns a little in neutral position, you can correct this with the trim lever below the steering wheel.
Press the lever in the appropriate direction until the motor has stopped and no longer beeps.
Throttle trim
ADJUSTING THE STEERING ANGLE
The maximum steering angle can be adjusted with the two buttons on the pistol grip. Pressing the upper button increa-
ses the the steering angle, by pressing the lower switch the angle is decreased.
Position 1: less control, the vehicle is less sensitive to steering commands of the steering wheel and is therefore easier
to drive - for slippery surfaces.
Position 2: more steering, the vehicle can run tighter turns, but because this it is to drive a little harder - for non-slip
surfaces or when driving on small places.
Caution: make sure that the steering arms (90165.13 do not touch on the C-hubs (90165.12), otherwise the servo gears
will be damaged!
With the servo end point adjustment (EPA), the steering angle can be adjusted separately for both sides, this may be
necessary if the steering angle is different on both sides even after correct steering trim. Read the corresponding section
of the remote control instructions!
2 1
Steering ST.D/R
First, charge the Low Rider battery with a suitable charger. You should also read the instructions of the charger and the
safety precautions listed before charging!
First switch on the transmitter and second the vehicle (the switch is located at the left side of the chassis). During swit-
ching on do not move the throttle trigger for a few seconds, so that the electronic speed controller can initialize itself cor-
rectly. The speed controller is correctly adjusted, when the red LED lits in neutral position, with throttle or brake engaged
the LED goes off. Consider that the speed controller does not go from braking directly into reverse, you must release the
throttle trigger and then go to reverse again.
Before you drive, check the correct function of the vehicle: does it react accurately on your remote control? If not, e.g.
the steering servo trembles or uncontrolled throttle reaction, do not start driving. Check whether the transmitter batteries
09 90163.RTR Low Rider Monster Truck 4WD
