Specifications

Monitor
Specifications
Diagonal:
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Video:
Input Signal
Sync:
Display Colors
Horizontal:
Synchronization
Vertical:
Range
Left/Right:
Viewing Angle
Up/Down:
Image Formation Time
Landscape:
Resolutions Supported
Portrait:
Active Display Area
Landscape : Horiz. :
Vert. :
Portrait : Horiz. :
Vert. :
Power Supply
Current Rating
Dimensions Landscape:
Portrait:
Height Adjustment:
Weight
Environmental Considerations
Operating Temperature:
Humidity:
Feet:
Storage Temperature:
Humidity:
Feet:
* Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This
1
is normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each
dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
LCD2080UX+manual0624.p65
MultiSync ® LCD
2080UX+
Monitor
20.1 inch
20.1 inch
1600x1200
ANALOG 0.7 Vp-p/75 Ohms
Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. Positive/Negative
Sync on Green (Video 0.7Vp-p and Sync Negative 0.3V p-p)
16,777,216
31.5 kHz to 91.1 kHz
50.0 Hz to 85.0 Hz
+88˚ (CR>10)
+88˚ (CR>10)
16ms (Typ.)
720 x 400* :VGA text
1
640 x 480* 1 at 60 Hz to 85 Hz
800 x 600* 1 at 56 Hz to 85 Hz
832 x 624* at 75 Hz
1
1024 x 768* 1 at 60 Hz to 85 Hz
1152 x 870* 1 at 75Hz
1280 x 1024* 1 at 60 Hz to 85 Hz
1600 x 1200 at 60 Hz ............................... display performance.
480 x 640* 1 at 60 Hz to 85 Hz
600 x 800* 1 at 56 Hz to 85 Hz
624 x 832* at 75 Hz
1
768 x 1024* 1 at 60 Hz to 85 Hz
870 x 1152* 1 at 75 Hz
1024 x 1280* at 60 Hz to 85 Hz
1
1200 x 1600 at 60 Hz ............................... display performance.
408 mm/16.1 inches
306 mm/12.0 inches
306 mm/12.0 inches
408 mm/16.1 inches
100 - 50/60 Hz
240 V ~
0.7 – 0.35A
442.0 mm (W) x 366.3 - 496.3 mm (H) x 200 mm (D)
17.4 inches (W) x 14.4 - 19.5 inches (H) x 7.9 inches (D)
340 mm (W) x 458.3 - 547.3 mm (H) x 200 mm (D)
13.4 inches (W) x 18.0 - 21.5 inches (H) x 7.9 inches (D)
130 mm / 5.1 inches (Landscape)
10.5 kg
23.1 lbs
5°C to 35°C/41°F to 95°F
30% to 80%
0 to 12,000 Feet
-10°C to 60°C/14°F to 140°F
10% to 85%
0 to 40,000 Feet
14
14
Notes
Active matrix; thin film transistor (TFT)
liquid crystal display (LCD); 0.255 mm dot
pitch; 250cd/m 2 white luminence; XtraView™
technology; 400:1 contrast ratio, typical
Digital Input: DVI
Depends on display card used.
Automatically
Automatically
Some systems may not support
all modes listed.
NEC-Mitsubishi Electronics Display cites
recommended resolution for optimal
Some systems may not support
all modes listed.
NEC-Mitsubishi Electronics Display cites
recommended resolution for optimal
7/9/03, 8:38 AM
