3. Initial start-up

3.3. Fastening on the VESA bracket

For fastening the monitor on a bracket, the foot can be removed as follows:
Diagram
When mounting the VESA bracket, please observe that the screws (M4) must not protrude
into the appliance by more than 8 mm max.
All manuals and user guides at all-guides.com
Procedure
Place the appliance cautiously onto an even
surface. If necessary, put a soft and clean cloth
underneath to prevent the LED screen from
becoming scratched.
Remove the two screws on the underside. Then
press the knob on the upper side and remove the
pedestal by turning to the right.
Unscrew the three remaining screws to
completely remove the mount.
