Parts List
Pièces détachées
パーツリスト
Ersatzteilliste
Parts List
En
Parts #
Description
341
SC-15 Electronic Speed Control With Reverse
1146
Firebolt 15T Motor (540 Type)
6122
Body Pin (Medium/10pcs)
6163
Servo Tape 20x100mm (5pcs)
6816
Silicone O-Ring S10 (6pcs)
6819
Silicone O-Ring P-3 (Red/5pcs)
6918
Pinion Gear 18 Tooth (48 Pitch)
85053
Shock Body Set (12x70-103mm/2pcs)
85054
Shock Body Set (12x67-87mm/2pcs)
Gear Diff Bevel Gears (13T/10T/4pcs) ( ax2, bx2, cx1, dx2 )
86014
86094
Screw Shaft M4x2.5x12mm (Black/6pcs)
86227
Diff Shaft 5x22.5x7mm (2pcs)
86228
Axle 5x36x7mm (2pcs)
86233
Dogbone 7x57mm
Bevel Gear Set 38/13T (Sintered Metal) ( ax1, bx1 )
86324
86810
Gear Shaft 5x6x29mm
86880
Slipper Pressure Plate (2pcs)
86882
Suspension Shaft 3x32mm (2pcs)
86887
Suspension Shaft 3x54mm (2pcs)
86896
Ball Stud 4.8x12mm (10pcs)
86900
Slipper Pad (2pcs)
86916
Shock Spring 13x57x1.1mm 14.5coils (2.4lb,Blue)
86946
Spur Gear 87T (48 Pitch)
88133
Shock Shaft 3x42mm (2pcs)
88134
Shock Shaft 3x50mm (2pcs)
100318
Shock Parts Set
Helmet Parts Set ( ax1 )
102832
103037
ST-8 Wheel Matte Chrome (0mm Offset/4pcs)
103045
Gear Box Set
Front Suspension Arm Set ( ax2 )
103047
103051
Shock Cap Set (Front/Rear)
Main Chassis ( ax2 )
103057
Steering Arm / Servo Saver Set ( ax1 )
103059
103199
Front Skid Plate/Bumper Set
103201
Rear Skid Plate/Bumper Set
103203
Front Roll Cage Set
Motor Mount Set ( ax1, bx1, cx1 )
103211
103218
Bulkhead Set
103229
Roll Cage Brace Set
Front Brace Set ( ax1, bx1 )
103232
103765
Yokohama Geolander M/T Tire D Comp (94x34mm/2pcs)
Ersatzteileliste
De
Nummer
Beschreibung
341
SC-15 Elektronischer Fahrtenregler (Rueckwaerts)
1146
Firebolt 15t Motor (540er)
6122
Karosseriesplinte Mittel (10 St.)
6163
Doppelseitiges Klebeband 20x100mm (5st)
6816
Silikon O-Ring S10 (6 St.)
6819
Silikon O-Ring P-3 (Rot/5st)
6918
Ritzel 18 Zaehne (48dp)
85053
Daempfergehaeuse Set (12x70-103mm/2st/Firestorm)
85054
Daempfergehaeuse Set (12x67-87mm/2st/Firestorm)
Kegeldiff Zahnraeder Inkl. Stift (4st) ( ax2, bx2, cx1, dx2 )
86014
86094
Gewindestift M4x2.5x12mm (Schwarz/6st)
86227
Diffwelle 5x22.5x7mm (2st)
86228
Achse 5x36x7mm (2st.)
86233
Knochen 7x57mm
Kegelrad Set (Gesintertes Metall/Mt2) ( ax1, bx1 )
86324
86810
Getriebewelle 5x6x29mm (Wheely King)
86880
Slipperscheiben (2st/Firestorm)
86882
Schwingenstift 3x32mm (2st/Firestorm)
86887
Schwingenstift 3x54mm (2st/Firestorm)
86896
Kugelkopf 4.8x12mm (10st/Firestorm)
86900
Slipperbelag (2st/Firestorm)
86916
Daempferfeder 13x57x1.1mm 14.5wdg (2.4lb/Blau)
86946
Hauptzahnrad 87z (48dp)
88133
Kolbenstange 3x42mm (2st/Brama 10b)
88134
Kolbenstange 3x50mm (2st/Brama 10b)
100318
Daempferteile Set (Firestorm)
Helm-Teile Set (Formula Ten) ( ax1 )
102832
103037
ST-8 Felge Matt-Chrom (0mm Offset/4st)
103045
Getriebebox Set
Schwingen Set Vorne ( ax2 )
103047
103051
Daempfergehaeuse Set (Vorne/Hinten)
Chassis ( ax2 )
103057
Lenkhebel / Servo Saver Set ( ax1 )
103059
103199
Skid Plate / Rammer Set Vorne
103201
Skid Plate / Rammer Set Hinten
103203
Ueberrollkaefig Set Vorne
Motorhalter Set ( ax1, bx1, cx1 )
103211
103218
Bulkhead Set
103229
Ueberrollkaefig-Streben Set
Streben Set Vorne ( ax1, bx1 )
103232
103765
Geolander M/T Reifen D Mischung (94x34mm/2st)
All manuals and user guides at all-guides.com
Parts #
103773
104144
104215
104717
104719
104721
104815
104851
105041
A431
B022
B030
Z150
Z242
Z243
Z264
Z299
Z481
Z517
Z518
Z519
Z526
Z527
Z561
Z567
Z569
Z571
Z573
Z578
Z579
Z581
Z663
Z684
Z700
Z705
Z713
Z852
Z892
Z901
Z904
Z950
Nummer
103773
104144
104215
104717
104719
104721
104815
104851
105041
A431
B022
B030
Z150
Z242
Z243
Z264
Z299
Z481
Z517
Z518
Z519
Z526
Z527
Z561
Z567
Z569
Z571
Z573
Z578
Z579
Z581
Z663
Z684
Z700
Z705
Z713
Z852
Z892
Z901
Z904
Z950
44
Description
Plastic Truck Bed Tires (2pcs)
Center Drive Shaft Set ( ax1, bx1, cx1, dx1 )
DT-1 Truck Body (Painted Color)
DT-1 Truck Body (Painted Color)
Rear Suspension Arm Set
Universal Joint Set ( ax2, bx1, cx1 )
Inner Body Set For Dt-1 Truck Body
Upright Set (Left/Right) ( ax1, bx1, cx2, dx2 )
Shock Spring 13x70x1.4mm 9.5coils (Black)
Diff Case ( ax1, bx1 )
Ball Bearing 5x11x4mm (2pcs)
Ball Bearing 10x15x4mm (2pcs)
Antenna Pipe Set ( ax1, bx1 )
E Clip E2mm (20pcs)
E Clip E3mm (10pcs)
Pin 2x10mm Silver (10pcs)
Step Screw M3x23mm (4pcs)
TP. Binder Head Screw M2.6x8mm (12pcs)
Binder Head Screw M3x8mm (10 Pcs)
Binder Head Screw M3x12mm (6pcs)
Binder Head Screw M3x15mm (6pcs)
Flat Head Screw M3x8mm (6pcs)
Flat Head Screw M3x10mm (6pcs)
Tp. Flanged Screw M3x10mm (6pcs)
Tp. Binder Head Screw M3x10mm (10pcs)
Tp. Binder Head Screw M3x15mm (10pcs)
Tp. Binder Head Screw M3x20mm (6pcs)
Tp. Binder Head Screw M3x25mm (6pcs)
Tp. Flat Head Screw M3x12mm (10pcs)
Tp. Flat Head Screw M3x15mm (12pcs)
Tp. Flat Head Screw M3x18mm (10pcs)
Lock Nut M3 (6pcs)
Flanged Lock Nut M4 (4pcs)
Set Screw M3x3mm (6pcs)
Set Screw M3x10mm (6pcs)
Set Screw M3x30 (10pcs)
Washer 5x7x0.2mm (10pcs)
Washer 10x12x0.2mm (10pcs)
Allen Wrench 1.5mm
Allen Wrench 2.0mm
Cross Wrench (Small)
Beschreibung
Plastik Reifen-Dummy (Fuer Vitrine/2st)
Mittelantriebs-Welle Set ( ax1, bx1, cx1, dx1 )
DT-1 Truck Karosserie (Lackiert)
O-Ring 4x7x1.5mm (8st)
Schwingen Set Hinten
Kardan Set ( ax2, bx1, cx1 )
Innenkarosserie Set Fuer DT-1 Truck Karosserie
Lenkhebeltraeger Set (Links/Rechts) ( ax1, bx1, cx2, dx2 )
Daempferfeder 13x70x1.4mm 9.5WDG (Schwartz)
Differentialgehaeusesatz ( ax1, bx1 )
Kugellager 5x11x4mm (2st)
Kugellager 10x15x4mm (2st)
Antennenrohrset ( ax1, bx1 )
E-Clip E2mm Silber (20st)
E-Clip E3mm (10st)
Stift 2x10mm Silber (10st)
Stufenschraube 3x23mm (4st)
Flachkopfschneidschraube M2.6x8mm (12st)
Flachkopfschraube M3x8mm Schwarz (10st)
Flachkopfschraube M3x12mm Schwarz (6st)
Flachkopfschraube M3x15mm Schwarz (6st)
Senkkopfschraube M3x8mm(6st)
Senkkopfschraube M3x10mm(6st)
Schneidschraube Mit Flansch M3x10mm (6st)
Flachkopfschneidschraube M3x10mm (10st)
Flachkopfschneidschraube M3x15mm (10st)
Flachkopfschneidschraube M3x20mm (6st)
Flachkopfschneidschraube M3x25mm (6st)
Senkkopfschneidschraube M3x12mm (10st)
Senkkopfschneidschraube M3x15mm (12st)
Senkkopfschneidschraube M3x18mm (10st)
Stoppmutter M3 (6st)
Stoppmutter M4 Mit Flansch (4st)
Madenschraube M3x3mm (6st)
Madenschraube M3x10mm (6st)
Madenschraube M3x30mm (10st)
Unterlagscheibe 5x7x0.2mm (10st)
Unterlagscheibe 10x12x0.2mm (10st)
Inbusschluessel 1.5mm
Inbusschluessel 2.0mm
Kreuzschluessel Klein
