4 Rotary and DIL switches
4.1 Setting the station number (rotary switch)
1
Address selector
switch for the units
figure
2
Address selector
switch for the tens
figure
4.2 Setting the field bus baud rate (DIL switch)
DIL switches
ON
1
2
3
4
Festo CP−FB11−E 0503f English
1
2
125 kBaud
ON
1
2
7 8
6
9
5
0
4 1
3 2
7 8
6
9
5
0
Example:
4 1
Set station number 38
3
2
250 kBaud
ON
1
2
500 kBaud
ON
1
2
