Timer of the heating / List of error messages
The indicator light flashes during heating and the value current
set for the power to be transferred in kW is shown on the display.
You can set the desired heating mode in the settings or switch it
over by activating the encoder for longer – the corresponding
Indicator light
Red
Flashing red
Green
Flashing green

10. Timer of the heating

The timer enables automatic termination of the heating. This
enables a relatively accurate dosing of the introduced energy
(heat) to the material, e.g. for selective or repeated heating to
the set temperature.
Activate the encoder again until the TIMER indicator light lights
up red . Turning sets the desired heating time in seconds, or
switch off the timer with the "OFF" selection.
If the timer is set, the indicator light lights up green at
the start of heating , if the heating is terminated by the
timer, the indicator light begins to flash green
text "OFF" is shown on the display after pressing the button.
Pressing the button ends the heating immediately. If the
heating is started in the timer setting, the remaining time of
the heating is displayed (minus the time of heating that has
already elapsed).
VIGOR GmbH
[ +49 (0) 21 91 / 97 95 • \ +49 (0) 21 91 / 97 96 00 • ] info@vigor-equipment.com • ^ vigor-equipment.com
Status
Setting for the heating power
in %, CP mode
Set power in kW during
heating
Setting for the force of the magnetic
field
in %, CF mode
Set power in kW during
heating
and the
• ; Am Langen Siepen 13-15 • 42857 Remscheid • GERMANY
designation of the CP/CF mode is shown on the display and
the colour of the indicator light changes. Activating the
encoder takes you to the setting for further parameters of the
induction heater, such as the timer of the heating etc.

11. List of error messages

Error Description of the error
code
1 Undervoltage in the power supply
2
Overvoltage in the power supply
3
4, 5
6
7, 8
Output frequency outside the range
9, 10, 11
12
13
14 – 18
Overheating of the device
19
Incorrect frequency of the power supply
20 – 256
Service error of the device
Input overcurrent
Output overcurrent
Power overload
Control error
Cooling fluid exhausted
Trapped or blocked hose
23
