restoring a scene (in groUp mode)
the indicator light flashes.
=
scene
buTTon
CanCellinG a Group of liGhtS
the indicator light flashes red then goes out.
10s
=
sTandby
buTTon
ConfiGurinG a Group of liGhtS
starting and exiting groUp conFigUration mode
after bringing together and close the lights to be grouped.
the indicator light flashes then lights up green at start (or lights off at exit).
3s
=
group
buTTon
1 remote control
per group
groUping lights aUtomatically (From groUp conFigUration mode)
from Group Configuration mode. Stand close to selected lights.
the indicator light flashes during the operation, then lights up green.
=
group
buTTon
12
Briefly press this button to restore the scene
(that is to say, the state of a group's lights) previously
recorded.
Press and hold (approx. 10 seconds) this button
to cancel the grouping of lights and restore
their original settings. the light flashes blue once.
to exclude one light from the group,
please refer to the light user manual.
Press and hold (approx. 3 seconds) this button to start Group
configuration mode. Press the button the same way to quit
the mode. this mode selects ten or so of the nearest lights
and displays their status (green or blue).
the light lights up green: it is already grouped
with the remote control.
the light lights up blue: it is available for grouping
with this remote control.
the light lights up red: it belongs to another group
(controlled by another remote control).
Briefly press this button to group the blue
lights among those selected.
(which then light up green as
they are selected).
Exit Group configuration mode to access to
light control. restart Group configuration
mode to group other lamps.
groUp or UngroUp indiVidUally the lights
from Group Configuration mode. Stand close to selected lights.
the indicator light flashes.
previous nexT
buTTon buTTon
groUp
bUtton

technical inFormation

technical characteristics
Battery: 3 V Lithium CR2450
life (battery): 2 years (standard use)
Radio frequency: 868 or 915 MHz (depending on
country)
splash
radio remoTe
radio range: 100 m maximum (direct range)
conTrol resisTanT
troUbleshooting gUide
you are unable to Control one (or SeVeral) liGht(S).
• Check that it is a K-BULB product (bulb with Kameleon technology).
• Start by charging the Bulb if you have not already done so.
• When using for the first time, you must first press one of the bulb's buttons to activate the radio transmission.
• For remote control, stand within radio range (as a precaution, maximum 50 meters from the lights with the remote control).
• If you are using your lights in Group mode, check that the light in question does in fact belong to this group
(if not, pair it with this remote control).
• If the problem persists, refer to the light user manual to switch it off and on, or restore its original settings
(note: in the second case, it will no longer belong to a group and will have to be regrouped as required).
• As a last resort, cancel the entire group using the remote control and then recreate it.
you are unable to pair (Group) a liGht.
• Check that the light in question is indeed free (if it is not, refer to the light user manual for cancelling its inclusion in another group).
• Stand in immediate proximity to the light (3 m max) to start Group Configuration mode (as the radio range in this mode is weaker)
and pair it with the remote control.
• If the problem persists, refer to the light user manual to switch it off and on, or restore its original settings,
then return to Group configuration mode to pair it.
compliance
In the European union (in accordance with directive dEEE 2002/96/Ec), and also in other regions, you must return this product to
a recycling collection point at the end of its life. as this product is not ordinary household waste, managing its end of life helps us
protect our environment and limit the use of our natural resources. for further information, please contact Smart & Green.
IPW Europe declares that this product complies with the following European directives: R&TTE (1999/5/EC), LVD (2006/95/EC),
RoHS (2011/65/EU), EMC (2004/108/EC) and Battery (2006/66/EC). The corresponding Declaration of Conformity
can be viewed on our website (www.smartandgreen.eu).
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
=
Briefly press one of these two buttons to select one light
among these kept once in Group configuration mode
(the next pressing selects another light).
=
Briefly press this button to change
the state of the selected light.
light ungroup
light group with remote control
Shock and uv resistant
Protection: IP44 (can be used in rain)
recommended operating temperature: 0 to 40°c
Product guarantee: 1 year
