INSTALLATION
3
1
M
Tighten 7/8" T-valve (M) to toilet TANK
water supply fitting . Do not hold fill
valve inside tank .
IMPORTANT: T-VALVE INSTALLS
AT THE BOTTOM OF TOILET
TANK, NOT AT THE WALL.
6
(continued)
P
2
H
I
B
1
J
K
L
www.RenewSeats.com
4
M
1
Connect water supply line coming
from the wall to bottom of T-valve (M) .
Connect cold water supply only . If your
supply line is rigid, you may need to
replace with a flexible hose line .
SEAT BRACKET & HARDWARE
Place adjustable seat bracket (B) over toilet
mounting holes .
Place hinge brackets (I) flat side down in
center of the square openings in the seat
bracket (B) .
Insert bolts (H) through hinge brackets (I)
and mounting holes . Square bolt head
should be even with sides of hinge brackets .
Slide rubber cone washer (J), washer (K),
and then nut (L) onto bolts under the toilet
bowl and lightly hand tighten to keep seat
bracket in place .
Continue with step 6 to mount seat .
