MONITOR

When the connections have been made, connect the short length of cable from the monitor to the connections bracket
and attach it as shown in the illustration.
1

ENTRANCE PANEL

Attach the support of the entrance panel to the wall. Then slide the pushbutton identifi cation cards of the entrance panel
into place, and make the electrical connections.
1
3
ENG-14
2-WIRE KIT VIDEO DOOR ENTRY SYSTEMS
2
20mm
2
PUSHBUTTON IDENTIFICATION
CARDS:
You can use either the preprinted
cards which are provided or print
your own using the template
available
Support section of the Alcad web
site: www.alcad.net.
20mm
from the Technical
