Extension Cable; Microsd Card Insertion - Eneo ISD-52F0023WSA Guide D'installation Rapide

Extension Cable

No. Connector
1 RJ-45
2 DC Jack
AI: Alarm In
3 G: GND
AO: Alarm Out
MIC: Audio In
4
G: GND
SPK: Audio Out
5
G: GND

microSD Card Insertion

Remove the cap at the bottom of the camera to insert the microSD memory card.
8
Description
Ethernet, RJ-45 port compatible with 10/100Mbps PoE Modular Jack
Main Power, DC Jack, DC12V
Alarm input and output, 3pin terminal
Audio line input, 2pin terminal
Audio line output, 2pin terminal
Reset Button
microSD Card Slot
