BAW M12MI-BLC35C-S04G and BAW M12MH-BLC70G-S04G
Inductive Linear Position Sensor
8
Accessories
8.1 Connection cable
BAW (I) Function
1 L+ (18 30 V)
...
2 Not used
3 L– (GND)
4 C/Q
Tab. 8-1: IO-Link Master pin assignment
Straight socket – straight plug
I
44.0
A
A
1
4 2
3
M12x1
Fig. 8-1: Straight–straight connector
Type
BCC M415-M413-3A-300-PX0334-010
BCC M415-M413-3A-300-PX0334-020
BCC M415-M413-3A-300-PX0334-030
BCC M415-M413-3A-300-PX0334-050
Angled socket – straight plug
I
38.2
A
A
3
2 4
1
Ø 14.5
Fig. 8-2: Angled–straight connector
Type
BCC M425-M413-3A-300-PX0334-010
BCC M425-M413-3A-300-PX0334-020
BCC M425-M413-3A-300-PX0334-030
BCC M425-M413-3A-300-PX0334-050
www.balluff.com
IO-Link Master (II)
1
–
3
4
II
Cable length
3
M12x1
Ordering code
BCC0370
BCC0372
BCC0373
BCC0374
II
Cable length
3
Ordering code
BCC037H
BCC037K
BCC037L
BCC037M
48.5
B
B
1
4
Examples:
BCC M415-M413-3A-300-PX0334-010 = cable length of 1 m
BCC M415-M413-3A-300-PX0334-050 = cable length of 5 m
48.5
B
B
1
4
M12x1
Examples:
BCC M415-M413-3A-300-PX0334-010 = cable length of 1 m
BCC M415-M413-3A-300-PX0334-050 = cable length of 5 m
english 19
