ISOMETER® iso685...
Schnittstellen
IP-Adresse ............................................................ manuell 192.168.0.5
Netzmaske ..................................................................... 255.255.255.0
Geräteadresse BS-Bus .........................................................................1
Sonstiges
Sprache .................................................................................... Deutsch
Inbetriebnahmeassistent ..................................................................an
Technische Daten
Isolationskoordination (IEC 60664-1/IEC 60664-3)
Bemessungsspannung ..............................................................1000 V
Überspannungskategorie (OVC) ........................................................III
Bemessungs-Stoßspannung (IEC 60664-1) .................................... 8 kV
Bemessungsisolationsspannung (IEC 60664-1) .........................1000 V
Spannungsprüfung, Stückprüfung (IEC 61010-1) ..................AC 2,2 kV
Versorgungsspannung
Klemme A1/+, A2/– ................................................ AC/DC 24...240 V
Klemme X1 ...............................................................................DC 24 V
Überwachtes IT System
Tensión nominal U
.................................AC 0...690 V, DC 0...1000 V
n
U
für UL Anwendungen ............................................ AC/DC 0...600 V
n
Ansprechwerte
Ansprechwert R
(Alarm 1) .......................................... 1 kΩ...10 MΩ
an1
Ansprechwert R
(Alarm 2) ......................................... 1 kΩ...10 MΩ
an2
Messkreis
Messspannung U
................................. profilabhängig, ±10 V, ±50 V
m
Messstrom I
.......................................................................... ≤403 μA
m
Innenwiderstand R
, Z
.............................................................≥124 kΩ
i
i
Zulässige Fremdgleichspannung U
Zulässige Netzableitkapazität C
.................................................................profilabhängig, 0...1000 μF
Schaltglieder
Kontaktdaten nach IEC 60947-5-1
Gebrauchskategorie ........... AC-13 AC-14 DC-12 DC-12 DC-12 DC-12
Bem.betriebsspannung .......230 V 230 V 24 V 48 V 110 V 220 V
Bem.betriebsstrom ...............5 A
Bemessungsisolationsspannung ≤2000 m NN ...........................250 V
Bemessungsisolationsspannung ≤3000 m NN ............................160 V
Minimale Kontaktbelastbarkeit ........................ 1 mA bei AC/DC ≥10 V
Sonstiges
EMV ................................................................................IEC 61326-2-4
Schutzart Einbauten (DIN EN 60529) .............................................IP40
Schutzart Klemmen (DIN EN 60529) ............................................. IP20
Entwicklung unter Beachtung folgender Normen: ...............................
isoxx685(W)-x-x ..........................................................DIN EN 61557-8
isoxx685(W)-x-P ........................................................ DIN EN 61557-9
14
iso685-x_D00022_11_Q_INTE/03.2021
...................................... ≤1200 V
fg
..........................................................
e
3 A
1 A
1 A 0,2 A 0,1 A
Interfaces
IP adress................................................................ manual 192.168.0.5
Network mask ................................................................ 255.255.255.0
Adress BS bus ......................................................................................1
Other
Language ................................................................................. German
Commissioning wizard ......................................................................on
Technical data
Insulation co-ordination (IEC 60664-1/IEC 60664-3)
Rated voltge ..............................................................................1000 V
Overvoltage category (OVC) ...............................................................III
Rated impulse voltage (IEC 60664-1) ............................................ 8 kV
Rated insulation voltage (IEC 60664-1) .....................................1000 V
Voltage test, routine test (IEC 61010-1) ................................ AC 2.2 kV
Supply voltage
Terminal A1/+, A2/– ............................................... AC/DC 24...240 V
Terminal X1 ...............................................................................DC 24 V
Sistema IT vigilado
Nominal system voltage U
.....................AC 0...690 V, DC 0...1000 V
n
U
for UL applications ................................................. AC/DC 0...600 V
n
Response values
Response value R
(Alarm 1) ........................................ 1 kΩ...10 MΩ
an1
Response value R
(Alarm 2) ........................................ 1 kΩ...10 MΩ
an2
Measuring circuit
Measuring voltage U
......................profile dependent, ±10 V, ±50 V
m
Measuring current I
.............................................................≤ 403 μA
m
Internal resistance R
, Z
..........................................................≥ 124 kΩ
i
i
Permissible extraneous DC voltage U
Permissible system leakage capacitance C
.................................................dependent on the profile, 0...1000 μF
Switching elements
Contact data acc. to IEC 60947-5-1
Utilisation category ............ AC-13 AC-14 DC-12 DC-12 DC-12 DC-12
Rated op. voltage ................230 V 230 V 24 V 48 V 110 V 220 V
Rated op. current. .................5 A
Rated insulation voltage ≤2000 m NN ........................................250 V
Rated insulation voltage ≤3000 m NN .......................................160 V
Minimum contact rating .....................................1 mA at AC/DC ≥10 V
Other
EMC ................................................................................IEC 61326-2-4
Degree of protection, built-in components (DIN EN 60529) ...........IP40
Degree of protection, terminals (DIN EN 60529) ............................IP20
Developed in compliance with the following standards: ......................
isoxx685(W)-x-x ..........................................................DIN EN 61557-8
isoxx685(W)-x-P ........................................................ DIN EN 61557-9
...................................≤ 1200 V
fg
...........................................
e
3 A
1 A
1 A 0.2 A
0.1 A
