Harmony Hi Lo Manuel D'assemblage Et D'utilisation page 14

STEP 8: SYNCHRONIZATION (OPTION)
Synchronization may be required for setting up two TXL Bases.
Insert one end of the Synch Cable (Optional A) into the Control Box of your
Adjustable Base. After completing the first five steps on the Second Base,
insert the other end of the Synch Cable (Optional A) into the Control Box of
the second TXL Adjustable Base.
STEP 9
Carefully flip over your topside-down Adjustable Base. Lift up the Base to desired location.
IMPORTANT NOTE:
Be Careful when flipping your Base:
The installed legs could get damaged or bent by excessive
pressure, if you lean your Adjustable Base on the legs.
1. Do not recline the Base against the installed legs to flip it
over.
2. Do not drag the Base across the floor.
STEP 10
Plug the AC Main Cable (C) in an electrical outlet with 100-240V, 50/60 Hz. A surge protector
(not included) is recommended for longer life of your Adjustable Base.
STEP 11
Take out Retainer (G) from your adjustable base. Insert Retainer (G) into the holes on the
Retainer Bar Fixation.
G
G
12
