SPECIFICATIONS
PRE-AMP SECTION
Line level inputs (Disc, CD, Video, Aux, Tuner, Tape1, Tape2)
Input impedance (R and C)
Input sensitivity (ref. rated power)
Maximum input signal
Signal / Noise ratio A-weighted 1
Signal / noise ratio pre-amp out, A-weighted
Frequency response 20Hz - 20kHz
THD + Noise, SMPTE IM
Line level outputs
Output impedance
Maximum output level
Tone controls
Treble
Bass
IR / Trigger out
Input resistance
Input voltage
Output resistance
Output current
Output voltage
POWER AMP SECTION
Continuous output power into 8Ω
Rated distortion (THD 20Hz - 20kHz)
Clipping power (maximum continuous power per channel 4Ω and 8Ω)
IHF Dynamic headroom
IHF dynamic power (maximum short term power per channel)
Damping factor (ref. 8Ω, 1kHz)
Input impedance (R & C)
Input sensitivity (rated output into 8Ω)
Voltage gain
Frequency response 20Hz - 20kHz
Signal/noise ratio, A-weighted
THD + Noise 3
SMPTE IM 4
IHF IM 5
Headphone output impedance

PHYSICAL SPECIFICATIONS

Dimensions (W x H x D)
Net weight
Shipping weight
1 From CD input to speakers output, volume setting for 500mV in, 8Ω 1W out
2 Minimum power per chnnel, 20Hz - 20kHz, both channels driven with no more than rated distiortion.
3 Total harmonic distortion, 20Hz - 20kHz from 250mW to rated output
4 Intermodulation distortion, 60Hz - 7kHz, 4:1, from 250mW to rated output
5 CCIF IM distortion, 19 + 20kHz rated output
Dimensions are of unit's cabinet without attached feet; add up to 18mm for total height.
Dimension depth excludes terminals, sockets, controls and buttons.
Pre-out
Pre-out
2
ref. 1W
ref. 50W
200kΩ + 320pF
220mV
6V
93.0dB ref. 1W
106dB ref. 500mV
<±0.1dB (Tone defeat on)
<±0.5dB (Tone defeat off)
< 0.01% at 5V out
80Ω
Tape Source Z + 1kΩ
>12V
Tape >10V
±5dB at 10kHz
±8dB at 100Hz
>10kΩ
Minimum 5V
<30Ω
50mA
12V
50W (17dBW)
0.03%
68W
8Ω +3.4dB
4Ω +5.0dB
8Ω 110W (20.4dBW)
4Ω 160W (22.0dBW)
2Ω 210W (23.2dBW)
>160
20kΩ + 470pF
630mV
29dB
29dB
100dB
117dB
<0.03%
<0.01%
<0.01%
220Ω
435 x 100 x 290mm
6.5kg (14.3lb)
8kg (17.6lb)
9
