oor magnet assembly
Step 2 (D
a) Align the hole on the front middle side of cart
base (A) with the hole on the latch magnet (W).
Insert a M6 x 15 bolt (AA) into each pre-drilled
b)
hole.
Tighten two bolts using the screwdriver
c)
provided.
Step 4 (Cart back panel assembly)
a) Align the holes on cart left panel (B) with the holes on the cart
back panel (D).
b) Insert one M6 x 15 bolt (AA) into each pre-drilled hole and
tighten bolts by hand.
c) Repeat the procedure with cart right panel (C) and cart back
panel (D).
d) Go back and tighten all bolts using screwdriver provided.
GSS2520JA
Instruction Manual
Guide d'utilisation
)
W
art side panel assembly
Step 3 (C
a) Loosen the six pre-installed bolts on the cart base and
leave 1/4 of the bolt's length extending from the cart
base (A).
b) Align the holes on the left side of cart base (A) with the
holes on the cart left panel (B) and tighten the
pre-installed bolts by hand.
c) Repeat the procedure with the cart right panel (C) on
the upper right side of cart base (A).
d) Go back and tighten all bolts using the screwdriver
provided.
D
8
)
AAX4
