PUSH-CA 30
Field of application
The PUSH-CA 30 actuator is used exclusively for opening and closing bottom-
hung, top-hung outward-opening, up-and-over and skylight windows. Use of
the actuator for other applications must be authorised by RIB and is subject
to technical testing of the application.
Description
1
Electrical actuator with chain and internal magazine. Ideal for bottom-hung
and top-hung outward opening windows with height of at least 20 cm. 230
Volt ac functioning. Selectable travel.
PUSH-CA 30 is fitted with a limit micro-switch, a removable terminal board
(fig. 4-B). It is also fitted with accessories and drilling template for fitting
the actuator to the window and special brackets for top-hung outward opening
and bottom-hung windows (available on request) (fig. 1-9, 1-4 and 1-2).
The chain has been treated with a Dacromet coating for protection against
oxidation under the most severe conditions.
Installation
2
!
The actuator must be installed by specialised technical personnel.
!
The actuator must be installed with the window closed.
!
Disconnect the electrical power supply during installation.
!
Check that the hinges and hardware used allow the actuator to open
fully. If not, the hardware may be damaged by the drive or thrust force of
the actuator (see travel adjustment).
a. With a pencil, mark the midline of the window. Apply the self-adhesive
drilling template (fig. 1-9) to the window and drill the holes using a drill and
drill bits with a diameter corresponding to the template.
b. Remove the self-adhesive drilling template and fit the bracket (5-4 and 6-A)
and the support (fig. 5-2 and 6-2) to the window and the frame respectively,
using the screws supplied. (N.B.: the screws are ideal for aluminium win-
dows. For wood applications, use diameter 4.8 wood screws with a length
suitable for the thickness of the wood - fig. 1-5).
c. The actuator (fig. 1-1) is supplied with a travel of 300 mm and can be
adjusted as follows:
Adjusting the travel using a cam
To modify the travel of the actuator chain, connect the actuator to the
mains (see point 3) or use the actuator test cable and then:
1. Power up the actuator.
2. Extract the chain by a length A equal to the travel required, as indi-
cated in Table A.
3. Remove the cover (see fig. 2-1 and 3-1)
4. Fit the travel setting fitting (see fig. 2-2 and 3-2). Example: with chain
A=0, the travel is 90 mm.
5. Refit the cover.
Note: For bottom-hung applications, adjust the travel before fitting
the actuator.
d. Fit the actuator to the bracket. Close the window, applying a light pressure
to guarantee that the gaskets are sealed. Then screw in the chain front pin
and adjust the position at the bracket.
e. Secure the actuator with the split pin (fig. 1-6). Ensure that the actuator
reaches the limit switch positions correctly without being obstructed. (NB.
The actuator is supplied with limit switch in the closed position).
Recommendations and safety standards:
- RIB products must be installed by specialised personnel with suitable tech-
nical skills.
- Perform the operations as specified by the manufacturer.
- The installer must check the installation and the correct functioning of the
device.
- Do NOT use the product for purposes other than those specified.
- Use original spare parts.
- Use the deadman command if the window is less than 2.5 m from floor
level.
Warnings:
- Check that the window components used allow the actuator to open fully. If
Standard supply
Every PUSH-CA 30 package contains the following (fig. 1):
1. 1 Actuator
2. 1 Actuator fixing support
3. 1 Front pin for chain
4. 1 Bracket for top-hung outward opening windows
5. 6 4.8x13 UNI 6954 self-tapping screws
6. 1 Split pin
7. 1 Cable clamp
8. 1 Securing pin
9. 1 Drilling template
10. 1 Travel adjustment fitting
1 Instructions booklet
Check that all the components are present and undamaged.
Technical data
THRUST FORCE
DRIVE FORCE
ADJUSTABLE TRAVEL
OPERATING SPEED
FRONT ADJUSTMENT
PARALLEL CONNECTION
SINGLE-PHASE POWER SUPPLY
CONSUMPTION
CURRENT
FREQUENCY
THERMAL PROTECTION
CAPACITOR
BUILT-IN RELAY
REMOVABLE TERMINAL BOARD
PROTECTION RATING
Electrical connection
3
Warning: injury or death - electrocution hazard. Disconnect the power
supply to the actuators before connecting the actuators or the system.
Warning: There must always be a multi-polar mains switch with a mini-
mum contact opening of 3 mm and a differential of 0.030 A upstream of
the actuator control line.
Check the cross-section of the power supply cable: it must have adequate
dimensions for the absorption of the actuator. Unscrew the two screws indica-
ted in fig. 7-1. The electrical connections are indicated in fig. 9. The electrical
system must comply with current standards.
N.B.: To ensure the system is safe, use a spring return push-button (dead man)
or a power supply which is timed for the time required for movement.
Maintenance
4
Once a year, check that the hinges are in good condition, check that the
actuator is firmly secured to the window and check the general condition
of the window. For perfect functioning, lubricate the chain with silicon
grease spray. Change worn parts.
At least every 12 months, test the product to ensure the system is
functioning correctly; for special systems, this check should be done at least
every 6 months.
N.B. Maintenance operations must be carried out by specialised per-
sonnel
not, the parts subject to stress or the actuator itself may be damaged.
- Attach a "BEWARE MOVING PARTS" adhesive label near the frame.
- Crushing or trapping hazard! The actuator has a drive and thrust force of
300N/150N. The hardware and the fittings for the accessories must be able
to support these loads.
- The window must have suitable support and safety systems; the actuator
cannot be considered as a support or safety device for the window.
- Do NOT touch the chain when it is moving.
- Keep outside the range of the window's movements when it is operating.
- The window must be fitted with safety arms which are suitable for the weight
of the window.
- Disconnect the electrical power supply when installing, adjusting and repai-
ring the actuator.
GB
150N
300N
from 90 to 300 mm
40mm/sec.
Max 10 mm
YES
230 V ac
150 W
0.8 A ac
50 Hz
100°C
4 micro Farad
YES
YES
IP 20
