Avtech PUSH VIDEO Installation Rapide page 3

4
Network Configuration from iPhone / iPad (Continued)
Step3: In the setting page, switch from "DHCP" to "Static", and change the port as needed.
You may change the default port number "88" to any value from 1 ~ 9999 (such as 8080) if "88" is blocked.
"80" is not recommended to use since many service providers block this port.
Then, write down the IP address and port number. You might need them in "5. Port Forwarding".
Step4: Select "Apply" to confirm all your changes, and WAIT till you see the message "Done" or "Fail" in "Status".
Regardless which message you see, proceed as instructed below:
For Done, you'll automatically return to the new device page.
For Fail, select "
" on the top right side. You'll be prompted to select "DDNS" or "Local
IP". Select "DDNS" and return to the new device page.
Step5: In the new device page, give a meaningful name for this connection in "Title", and select "Save".
Step6: Check if the Internet status indicator ( ) is always on. If yes, go to
Step3
6
Check Your Connection
When you complete the network setup, check your
connection as instructed below.
Step1: Check if the LAN ( ) and Internet ( ) status
indicators on the camera are both always on.
If yes, go to Step2 below.
If is blinking, go to 5 .
Step2: Switch the network mode to 3G mode on
iPhone or iPad.
Step3: Start EagleEyes, and select the connection you
just added to see if you can access the camera
successfully.
If yes, your network setup is successful.
If no, the port number you're using for the
camera might be blocked by your phone carrier.
Go to 4 , change the port number as instructed
in Step3, and click "Apply" to save your setting.
Then, return to 6 to examine your connection
again.
6 5
; if no, go to .
Step4 Step5
7
Change Default Account
To ensure your account safety, after finishing network
setup, please access the camera, and select "
"Advance Setup"  "Account" to change the default
password with a new one you prefer.
Default Values
IP Address Ethernet 192.168.1.10 User Name
Wireless 192.168.2.10 Password
Port 88
Status Indicator
Internet
Indicator LAN
Always On Connected Connected
Blinking* Disconnected Disconnected*
* The network setting is not completed when the Internet
indicator is blinking in the fashion below:
5 seconds on  0.5 second off  0.5 second on  0.5
second off  5 seconds on
For details, please download the "Operation Guide" from:
www.surveillance-download.com/user/n812.swf
5
Port Forwarding
When the Internet status indicator ( ) is blinking in the fashion below:
Continue for port forwarding:
Check if your router is configured to Internet:
Step1: Open the web browser on iPhone / iPad, and enter the IP address of your wireless router noted down in (
(such as "192.168.2.1" in our example) to access.
Step2: Go to the port forwarding (or virtual server) rule configuration page.
The naming of port forwarding or virtual server may vary based on different router brands. To know
where it is, please refer to the user manual of your wireless router.
Then, enter the IP address and port number you have written down in "Step3" of
Take D-Link wireless router as an example:
ADVANCED
PORT
FORWARDING
192.168.2.105
6
Step3: Continue to to example your connection.
Q&A
For more details about EagleEyes Q&A, please visit our official website:
www.eagleeyescctv.com/supp_QnA.aspx.
Q1: Does this camera support quick wireless connection setup with just one press?
"  A1: Yes, and this support must work with the router which also supports quick wireless connection setup. Users do not need to
manually search and enter the password to join the wireless network. All setup and connection can be done with just one press.
To use this function, your router must be compatible with WPA or WPA2 security. And the naming of this function may vary based
on the brand of each router. For details, please check the user manual of your wireless router.
Q2: I can't connect to this camera with 3G network, but it works with my wireless network. Why?
A2: Your network configuration is not yet completed, or the port number used for the camera is blocked by your mobile carrier.
Please examine your connection as instructed in
admin
4
admin
Q3: My live images are not fluent. Why?
A3: Image fluency could be affected by the local network upload bandwidth, router efficiency, client network download bandwidth,
complexity of live view, and more.
(Available for remote access from Internet Explorer and iPad only) To have the best image fluency, select QVGA; to have the best
image quality, select "SXVGA"; to have normal image fluency and quality, select "VGA".
Q4: The detection range of the built-in human detection sensor seems too short and the sensor is not sensitive enough. Did I do
anything wrong on installation?
A4: The human detection sensor might be influenced by the temperature of ambient environment and human beings, and the applicable
working temperature is up to 30 o C. To get more accurate and precise detection, you may connect external alarm devices, such as
magnetic contacts.
There're some tips for installation. For details, please visit and search our Q&A section in www.eagleeyescctv.com/supp_QnA.aspx.
Q5: The live video keeps flickering. Why?
A5: Please try adjusting the power line frequency to "60 Hz" or "50 Hz" from your iPhone by selecting "
Configuration page. Then, go to "Advance Setup"  "Camera" to change setting.
5 seconds on  0.5 second off  0.5 second on  0.5 second off  5 seconds on
0.25 seconds on  0.25 second off  0.25 second on  0.25 second off
Go to "ADVANCED"  "PORT FORWARDING".
IP Address: The IP address assigned to this camera,
such as 192.168.2.105 in our example.
Ports to Open: The port number you specified to this
camera, such as 88 in our example.
6
.
* iPad ® & iPhone
2
4 , and enable this rule.
" to enter IPCAM
® are the registered trademarks of Apple Inc.
