Output
Table 1
kW
6 6
CORE
9 9
CORE
CORE
10,5
10,5
* There must always be a minimum of 20 mm between the outer surface of the finish
and the wall
NB! The CORE unfinished heater needs finishing. See Appendix 1 (pages
12-13) Recommendation for finishing installation.
NB! The heater including finishing can become very heavy and difficult
to turn to have an electrical connection. Before installing the finish and
riveting the slats, connect the wires from the bottom and check the
operation of the heater.
INSTALLATION
Positioning the heater
• The heater must be positioned in such a way that there is a safe
distance between flammable materials and the external surfaces
of the heater. See Figure.
• In installing the heater, it must be prevented that people could
have physical contact with the heater or that other dangerous
situations could emerge during the heating process.
• The inputs of the power cable are on the bottom cover of the heater.
Connecting the heater to the power supply
• Only a certified electrician is allowed to connect the heater to the
power supply.
• A rubber insulated SIHF-JB cable or an equivalent cable must be
used as the connection cable.
• The maximum current intensity in the cross-sectional area of the
cable and circuit breaker are listed in Table 1.
• It is recommended to connect the unit to the mains without an
earth-leakage circuit breaker.
Room Weight
m kg
3
6–10 15 min 40*
9–15 15 min 40*
10-20 15 min 40*
Width/
A H
Depth
mm mm
mm
830 385/385
830 385/385
830 385/385
Circuit Power
Breaker cable
A N × mm
10 5 × 1,5
16 5 × 2,5
16 5 × 2,5
