ENGLISH
D. You will see notice that the first LED projector in the chain is lit.
E. Press the "sound to chase" button (see n°6) to select all projectors: all projectors are lit!
F. Press the "random chase" button (see picture )
G. Press the "blackout" button again for about 5 seconds, until the "blackout" LED stops blinking.
H. Done!
3. SEMI AUTOMATIC ADDRESS DISTRIBUTION :
Important: works only with projectors that are compatible with our remote DMX-addressing function.
The user can determine the order of succession of the LED projectors: you have full impact on the
configuration but it takes more time to set up an installation with many projectors.
A. First determine if you will put the LEDCON-02 MK2 in 4 or 8 channel mode (see switch n°12)
B. Connect all projectors to the LEDCON-02 MK2 and switch the complete setup on.
C. Press the "blackout" button (see n°8) for about 5seconds: until the red "blackout LED" starts blinking.
D. You will see notice that the first LED projector in the chain is lit. Now you can determine the address
of this projector by pressing the corresponding color/chase button (see n°1):
Press button "chase1"  the current LED projector receives address 1
o
Press button "chase2"  the current LED projector receives address 2
o
Press button "chase3"  the current LED projector receives address 3
o
Press button "chase4"  the current LED projector receives address 4
o
Press button "chase5"  the current LED projector receives address 5
o
Press button "chase6"  the current LED projector receives address 6
o
Press button "chase7"  the current LED projector receives address 7
o
Press button "chase8"  the current LED projector receives address 8
o
E. Press the "full on" button (see n°7) to select the next projector and return to "D" until all projectors
received an address. If you want to select the previous projector, simply press the "sound to chase"
button (see n°6). Several projectors can be put on the same address.
F. When all projectors received an address, press the "blackout" button again for about 5 seconds, until
the "blackout" LED stops blinking.
G. Done!
SPECIFICATIONS
Power Input:
AC/DC Power adapter:
DMX output:
DMX channel setup:
DMX address distribution:
Audio input:
Size:
Weight:
You can download the latest version of this user manual on our website: www.jb-systems.eu
JB SYSTEMS
®
DC 9V 300mA minimum.
AC 240V, 50Hz  9Vdc / 300mA (or more)
3pin XLR
CH1= RED * CH2=GREEN * CH3=BLUE * CH4=DIM / STROBE
projector1 = address 001
Projector2 = address 005
Projector3 = address 009
Projector4 = address 013
Projector5 = address 017 (only for 8channel mode)
Projector6 = address 021 (only for 8channel mode)
Projector7 = address 025 (only for 8channel mode)
Projector8 = address 029 (only for 8channel mode)
None, internal microphone
21,0 x 14,0 x 4,6cm
930 grams
Every information is subject to change without prior notice
