Sony Bravia KD-49XG90 Séries Guide De Référence page 12

LAN
10BASE-T/100BASE-TX connector (Depending on
the operating environment of the network,
connection speed may differ. The communication
rate and quality are not guaranteed.)
5
IR BLASTER*
IR Blaster Cable input (mini jack)
Others
Optional accessories
Wall-Mount Bracket: SU-WL450
Operating temperature
0 ºC – 40 ºC
Operating humidity
10 % – 80 % RH (non-condensing)
Power, Product Fiche and others
Power requirements
220 V - 240 V AC, 50 Hz
Energy Efficiency Class
B
Screen size (measured diagonally) (Approx.)
123.2 cm / 49 inches
Power consumption
In [Standard] mode
114 W
In [Vivid] mode
199 W
Annual energy consumption*
158 kWh per year
Standby power consumption*
0.50 W (27 W in software/EPG update mode)
Display resolution
3,840 dots (horizontal) × 2,160 lines (vertical)
Output Rating
USB 1/2
5 V , 500 mA MAX
USB 3
5 V , 900 mA MAX
Dimensions (Approx.) (w × h × d)
with Table-Top Stand
109.3 × 69.9 × 27.4 cm
without Table-Top Stand
109.3 × 62.9 × 6.9 cm
Mass (Approx.)
with Table-Top Stand
14.6 kg
without Table-Top Stand
13.5 kg
12
GB
6
7 8
*
*1 Not all the TV sets have DVB-T2 or DVB-S/S2
technology or satellite antenna terminal.
*2 When 4096 × 2160p is input and [Wide mode] is set
to [Normal], the resolution is displayed as 3840 ×
2160p. To display 4096 × 2160p, set [Wide mode]
setting to [Full 1] or [Full 2].
*3 HDMI IN 2/3 only. To support 18 Gbps, set [HDMI
signal format] to [Enhanced format].
*4 Refer to the Help Guide for details.
*5 Only on limited region/country/TV model.
*6 Energy consumption in kWh per year, based on the
power consumption of the television operating
4 hours per day for 365 days. The actual energy
consumption will depend on how the television is
used.
*7 Specified standby power is reached after the TV
finishes necessary internal processes.
*8 Standby power consumption will increase when
your TV is connected to the network.
Note
• Do not remove the dummy card or cover (availability
depends on TV model) from TV CAM (Conditional
Access Module) slot other than to insert a smart card
fitted in CAM.
• Optional accessories availability depends on
countries/region/TV model/stock.
• Design and specifications are subject to change
without notice.
Notes on Digital TV function
• Digital TV (DVB terrestrial, satellite and
cable), interactive services and network
functions may not be available in all
countries or areas. Some functions might
not be enabled or might not operate
correctly with some providers and network
environments. Some TV service providers
may charge a fee for their services.
• This TV supports digital broadcasting using
MPEG-2, H.264/MPEG-4 AVC and H.265/
HEVC codecs, but compatibility with all
operator/service signals, which may
change over time, cannot be guaranteed.
Trademark information
• The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo
are trademarks or registered trademarks of
HDMI Licensing Administrator, Inc. in the
United States and other countries.
• Dolby, Dolby Vision, Dolby Audio, and the
double-D symbol are trademarks of Dolby
Laboratories. Manufactured under license
from Dolby Laboratories. Confidential
unpublished works. Copyright © 1992-2015
Dolby Laboratories. All rights reserved.
• "BRAVIA",
trademarks or registered marks of Sony
Corporation.
and BRAVIA Sync are
