Operating Instructions
V
11,8
10,0
0
V
11,8
10,0
0
UL
Lower limit of measuring range
Figure 19: Behavior of the analog output in the event of an error (2) Significant "overrunning" of the output voltage of 10 V to increase the
reliability of the system in the case of stray voltage.
1 0 2 O p e r a t i n g I n s t r u c t i o n s | S I C K
Errors
Analog output
0 V ... 10 V
(normal function)
Analog output
0 V ... 10 V
(interverted mode)
 10 V ... 0 V
OL
Upper limit of measuring range
p
p
