Instrument Panel (Fig.3) - Mase Generators Ea 50 R Manuel D'utilisation Et D'entretien

The generators of the EA series are essentially composed of the following components:
- Engine air filter (Fig. 2 Ref. 1)
- Knob for pull-start
- Petrol-powered internal-combustion engine (Fig. 2 Ref. 3)
- Terminal for earth connection of generator(Fig. 2 Ref. 4)
- Alternator unit (Fig. 2 Ref. 5)
- Instrument and outlet panel (Fig. 2 Ref. 6)
- Engine exhaust (Fig. 2 Ref. 7)
- Load-bearing chassis (Fig. 2 Ref. 8)
- Lifting hook (Fig. 2 Ref. 9)
- Fuel tank (Fig. 2 Ref. 10)
- Fuel closing tap (Fig. 2 Ref. 11)

2.4 Instrument panel (fig.3)

Each generator is fitted with an instrument panel for the controls carrying the following components:
1) Single-phase thermal switch
2) Schuko outlet, 16A 2P+GND
3) Three-phase thermal switch
4) EEC outlet, 16A 400V 3P+GND
EA 50 R - EA 80 R - EA 60 RT - EA 90 RT
