Choosing the Rated Speed:
The rated speed should be set to correspond to the volume to ventilate or the surface area of the
premises.
For the Galbé and Cube models:
Surface area of the
space to ventilate* (m²)
0 to 24
25 to 61
62 to 74
75 to 80
81 to 90
91 to 97
98 to 122
123 to 148
149 to 164
165 to 174
For the Urban model:
Surface area of the
space to ventilate* (m²)
0 à 24
25 à 48
49 à 56
57 à 65
66 à 75
76 à 88
89 à 102
103 à 118
119 à 138
139 à 160
For the MAXI model housing:
Surface area of the
space to ventilate* (m²)
0 to 87
88 to 131
132 to 157
158 to 182
183 to 207
208 to 232
233 to 257
258 to 282
283 to 307
308 to 320
The above data comes from measurements made in a laboratory, so discrepancies with these
measurements may be observed.
* for premises with an unchanging ceiling height of 2.5 m.
Volume to ventilate
(m3)
0 to 60
60 to 154
155 to 184
185 to 200
201 to 224
225 to 242
243 to 306
307 to 370
371 to 410
411 to 436
Volume to ventilate
(m3)
0 à 60
61 à 120
121 à 140
141 à 162
163 à 187
188 à 220
221 à 255
256 à 295
296 à 345
346 à 400
Volume to ventilate
(m3)
0 to 217
220 to 327
330 to 392
395 to 455
457 to 517
520 to 580
582 to 642
645 to 705
707 to 767
770 to 800
Flow rate (m3/hr)
30
77
93
100
112
121
153
185
205
218
Flow rate (m3/hr)
33
59
69
80
97
107
126
151
176
201
Flow rate (m3/hr)
70
150
181
213
244
275
306
338
369
400
Rated speed to set*
V1
V2
V3
V4
V5
V6
V7
V8
V9
V10
Rated speed to set*
V1
V2
V3
V4
V5
V6
V7
V8
V9
V10
Rated speed to set*
V1
V2
V3
V4
V5
V6
V7
V8
V9
V10
