2.4.3.2 Presentation of the pictograms
Main screen
Ambient temperature measured in the living area where the remote
control is located.
Air quality indicator according to humidity. The more the cursor is to the
left, the drier the air; the more it is to the right, the more humid the air.
The middle position corresponds to the most comfortable conditions.
Filter status display.
When the filter is orange, we recommend that you order a new filter
from your installer.
To change the filter (see chapter 6.1)
Manual mode activated.
Warning: when this mode is active, the automatic functions are no longer
operational.
Malfunctioning detected.
Contact your installer.
Radio reception quality indicator. If the reception is bad, move your
remote control closer to the VMI® unit.
Battery indicator for the 2 AA LR6 batteries
To change the batteries (see chapter 6.3)
Indicator for the minimum set temperature for preheating the blown air.
N.B. The lower the set temperature, the lower the power consumption.
You are advised to cut the set temperature during the hot season.
Fan operating speed indicator. In automatic mode, the speed may vary
depending on various parameters to adjust the ventilation flow rate to
the requirements of the premises.
Ventilation cooling mode activated (automatically activated). The air flow
rate is increased to cool down the premises and make your environment
more comfortable during the summer.
Summer mode activated (automatically activated).
Given the outside temperatures, the VMI® unit detects that the incoming
air no longer needs to be preheated ("freeze protection" mode activated
Turbo heat mode activated (automatically activated). The air flow rate is
increased when the outside temperature is higher than the set
temperature in winter. This means that you recover free heat.
Boost mode activated (activated by the user via the specific screen). With
this mode, the flow rate is increased for 30 minutes to renew the air
more quickly.
Holiday mode activated (activated by the user via the specific screen).
With this function, the ventilation and preheat functions are set to a
minimum ("freeze protection" mode) when the user is absent.
STANDBY mode activated (automatically activated).The VMI® unit turns
at minimum speed and desactivates air preheating if the outside
temperature exceeds the maximum temperature threshold or if the
VMI® unit malfunctions.
