Item.-No.
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
All spare parts which are not marked with an „X", are safety related parts or in connection with
safety related parts of the machine. The assembly should be made by WDT.
If the replacement of the safety related parts or parts, which are in connection with these
safety related parts is done by the end-user, every guarantee- and warranty claim expires. The
manufacturer excludes any kind of liability for accidents, which are caused of the incorrect
replacement.
BDA UP 14 Z – 03/15 – REV. 0
Pcs WDT-P/N
1 8480-99121
1 1481-14001
6 8481-02008
2 8481-01003
1 1480-89002
1 8550-00008
1 1481-01006
1 5480-88002
1 5480-81005
1 5481-14003
1 5481-03003
1 5481-02006
1 5481-03005
1 5481-14002
2 5480-81027
2 5481-14001
1 1481-14002
1881-02002
Spare Part
Hex. Socket screw M3x14 DIN912
Cover complete with holes
Lens head screw M5x12 (galvanized-
X
blue)
X Hex. Socket screw M4x8 DIN7984
X Locator holding fixture
X Lens head screw M4x12
X Safety Guard complete. CK100 / CS30
X Label "Hinweis Fingerschutz"
Label "Warnung vor
X
Handverletzungen"
X Label "Release"
X Label "A"
X Label "P"
X Label "P2"
Label "Serien-Nr."
X Label "WDT" red
X Label "UP 14 Z" black
Pneumatic complete
Hexagon wrench Key Set
Description
Page 46 / 71
