8. Adjustment
Once the displays are adjusted to their
final desired position, tighten the collars
on the Top and Bottom Poles using a
3mm Hex Key.
14-06-218-933380.indb 11
It may be necessary to slightly loosen or
tighten the adjustment screw depending
on the weight of display installed.
3mm
Hex Key
11
180°
180°
180°
Adjust to the desired position or tilt.
4mm
Hex Key
+15°
360°
– 15°
