EN | F.DUAL HOB
5 ADAPTING TO DIFFERENT TYPES OF GAS
If the appliance is set-up to operate with other types of gas, proceed as follows:
• replace the nozzles of the burner
• adjust the minimum flame setting
5.1 REPLACING NOZZLES
• remove the grill and the caps and flame ring.
• remove the nozzles using a 7 mm wrench and replace them with the standard nozzle for the desired type of gas.
ATTENTION: For the changeover to natural gas, mount the nozzle marked 70 in the inner ring and the nozzle marked 140 in the outer ring
• reposition the flame ring and the caps in their seat and assemble the grill.
5.2 ADJUSTING THE MINIMUM FLAME SETTING
• Turn on the burner and set the knob to the minimum position
pull out the knob of the gas tap (fig. E) and use a screwdriver (fig. F) to turn the adjustment screw on the side (fig. G) until the correct minimum
flame is achieved.
Make sure the flame stays in contact with the tip of the thermocouple to prevent the flame from going out during use.
• replace the knob and position it in the minimum position
the side (fig. H) until the correct minimum flame is achieved.
FIG. E
5.3 CHANGING OF TECHNICAL LABEL
After adapting the appliance to a different type of gas from the factory-set gas, replace the silver technical label on the barbecue with the one
corresponding to the new gas. Insert the label inside the bag of the nozzle replacement kit.

6 MAINTENANCE AND WARRANTY

• For a good preservation of the surfaces, it is necessary to clean them regularly at the end of each use.
• For stainless steel parts, it is recommended to use CLEAN INOX, a specific detergent for stainless steel which removes any dirt or oily marks
deposited on the surface of the structure: it does not contain any abrasives or chlorine-based acid substances.
• Spray on the surface, rinse thoroughly and dry with a soft cloth or a microfiber cloth.
• Do not use any steam jets to clean the appliance.
• Do not use any rough, abrasive materials or sharp metal scrapers.
• Grids, caps, gas rings and burners are removable for easy cleaning; wash them with hot water and detergent – thus avoiding the use of
abrasive or chlorine-based corrosive cleaners – taking care to remove any deposits and wait until they are perfectly dry.
• FOR MORE INFORMATION PLEASE REFER TO "INSTRUCTIONS FOR USE AND MAINTENANCE – PLANET WARRANTY" MANUAL.
• FOR ANY TECHNICAL ISSUE PLEASE CONTACT THE TECHNICAL ASSISTANCE.
24
of the inner ring.
MIN 2
of the outer ring and repeat the operation by turning the adjustment screw on
MIN 1
MAX 2
FIG. F
