A
70
77 1/2"
PIVOTING LINEN CABINET/
DRESSING TABLE
A
MAIN LIGHTING
Bring out an AC 110V 2-14 and
connect to the transformers in
the junction box on the top of
the linen cabinet.
D
PLUMBING FOR ESKR-8 SINK
The drain output is in the
center of the sink and the
water outlets are aligned with
faucets.
This type of plumbing
applies only on the ESKR 8.
DRAIN POSITIONING
D
ESKR-1 CENTERED
Slate sink
Drain
Always in the
30"
15"
center of the
36"
18"
countertop
42"
21"
48"
24"
and the sink
27"
54"
base
6
B
1/2"
Plumbing for
ESKR-8 sink
3"
D
12"
12"
ASK AN ELECTRICIAN TO MAKE THE CONNECTIONS
HORIZONTAL MIRROR
MAIN LED LIGHTING AND MOOD
B
LIGHTING
Install in the wall 2 recessed Duplex
receptacles 15A-125V (not included), side
by side at 65 ¼" to center from the fl oor
and centered with the sink. One of the
Duplex receptacles must be connected to
the main switch (for lighting above mirror).
The other one must have an AC (alternating
current) for motion activated lighting under
the mirror.
Note: The positioning of the
outlets must be precise because there is
not much free space.
E
PLUMBING FOR ESKR-1 AND ESKR-2 SINKS
The drain output is centered with the drain
and the water outlets are on each side of
the drain at 29 ½" from the fl oor.
of plumbing applies on the ESKR-1 and
ESKR-2 sinks. See below the exact drain
positioning.
D
ESKR-1 OFF-CENTERED
Slate sink
Drain
Can be off-
36"
15"
centered
42"
17 ½"
to the right or
48"
20"
54"
22 ½"
to the left.
ELECTRICITY AND PLUMBING
75
65 1/4"
3"
28
1/2"
This type
D
ESKR-2 OFF-CENTERED
Slate sink
Drain
72"
19"
78"
19"
84"
19"
Vertical medicine cabinet
C
32"
78"
18"
5/8"
62
1/2"
VERTICAL MEDICINE CABINET
MAIN LED LIGHTING AND MOOD
C
LIGHTING
A recessed Duplex receptacle (not included)
must be installed at 62 ½" to center from the
fl oor and centered with the sink base. The
top section must be connected to the main
switch while the bottom section should be
powered by an alternating current. Plug the
transformer supplying the headlight at the
top of the socket. Connect the bottom of
the socket to the transformer that powers
the light under the medicine cabinet.
Note: The positioning of the outlet must be
precise because there is not much free space.
Plumbing for ESKR-1
4"
E
28
1/2"
D
D
ESKR-8 CENTERED
Slate sink
60"
66"
72"
78"
84"
B
C
Recessed Duplex
receptacle
15A-125V
(not included)
Z shape
metal support
bracket.
and ESKR-2 sinks
29
1/2"
Drain
Always in the
30"
center of the
33"
countertop and
36"
39"
the sink base
42"
