I. Parts List
II. Characteristics
I. PARTS LIST
1. Hook
2. Cable
3. Rim
4. Crank
5. Axis bolt
6. Base
7. Ratchet switch
Note: The PRTRM2000 / 560216 winch has 2 separate axes (Fig.1b). Each axis has its own
transmission ratio. You can choose to tow quickly (axis b Fig.1c more force is needed) or slowly
(axis a Fig.1c: less force is needed, more suitable for towing heavy objects).
Fig.1c
II. CARACTERISTICS
Reference
Model / Type
Steel Cable length
Cable resistance
Cable tensile strength
Hook Dimensions
Mounting plate (mm)
Overall Dimensions (mm)
Net weight (Kg)
(*) Cable resistance to traction
Winch capacity according to type of load :
(R) Rolling load
(M) Marine load
(T) Pulling load (Traction)
III. Safety Instructions
IV. Getting Started
Fig.1a (
PRTRM1000
PRTRM1000 / 560106
10m x 4.5mm
Max. 675 Kg (*)
2
1640 N/mm
1/4"
137 x 87 x 2.5 mm
232 x 245 x 150 mm (approx)
3.0
V. Operation
VI. Maintenance and Storage
)
KC1200
PRTRM1000 / 560106 PRTRM2000 / 560216
KC1200
Lbs
1200
1000
400
Fig.1b (
PRTRM2000
PRTRM2000 / 560216
KC2500
10m x 5mm
Max. 1650 Kg (*)
2
1640 N/mm
1/4"
183 x 118 x 4 mm
308 x 280x 178 mm (approx.)
5.2
KC2500
Kg
Lbs
540
2500
450
2000
180
800
)
Kg
1100
900
360
