EN
Specification
Electrical
Item
Operating Temp.
Storage Temp.
Environment
Relative Humidity
Vibration
Safety standards
Safety
&
EMC standard
EMC
Dimension-Module
Others Dimension-Shelf
Weight (net)

2-3. Block Diagram

2-4. Mechanical Drawings

2-4-1. SR-1600 Plus Single Module

SR-1600
Plus-124
-25°C ~ 40°C; refer to SR-1600 Plus power de-rating curve
Certificated FCC Class B
Table 1. SR-1600 Plus specification
Figure 1. SR-1600 Plus mechanical drawing-single module
Model No.
SR-1600
Plus -148
-40℃~70℃
95%, non-condensing
Meet BS EN 61373
Meet UL 62368-1
105x83x410 mm / 4.13x3.27x16.14 inch
446x85x509mm / 17.56x3.35x20.04 inch
Module：3.8kg; 4pcs / Shelf：6.5kg; 1pcs
SR-1600 SR-1600
Plus -224 Plus -248
Certificated EN 62368-1
Certificated EN 55032 Class B;
EN 55024; EN 300386;
EN 61000-3-2, -3-3, -6-1, -6-3;
IEC 61000-4-2, 3, 4, 5, 6, 8, 11
5
