Specifications; Declaration Of Conformity - DNT DigiMicro Profi II Mode D'emploi

Specifications

Specifications
Image Sensor
Video Resolution
Still Capture Resolution 2592x1944, 2320x1744,2048x1536,1920x1080, 1280x1024 Pixel
Colour
Focus Range
Flicker-Frequenz
Framerate:
Magnification Ratio
Image Format
Video Format
White Balance
Light Source
PC Interface
OS
DC Power
Microscope
Stand

Declaration of Conformity

Hereby, dnt GmbH, declares that this DigiMicro Profi is in compliance with the essential requi-
rements and other relevant provisions of Directive 2014/30/EU.
The declaration of conformity is available for download www.dnt.de/konformitaet
Continuous Line Measurement. The Continuous Line
measurement allows you to measure any continuous desired
length. Simply click and drag from one point to other desired
points, and then release the click.
Radius Circle Measurement. Simply click and extend out to the
desired radius, the radius, circumference and area of the circle
will show up accordingly.
Diameter Circle Measurement. Simply click and extend out to
the desired diameter, the diameter, circumference and area of
the circle will show up accordingly.
Three Points Angle Measurement. Simply define any three
points angle and click, the angle value will then display.
5 Mega Pixels
2592x1944, 2320x1744,2048x1536,1920x1080, 1280x1024 Pixel
24-Bit-RGB
manual focus from 10mm to 100mm
50/60 Hz
max. 30 frames/s
ca. 20 - 300x
JPG
AVI
automatic
8 LED, white
USB 2.0
Windows 7, Windows 8, Windows 10, MAC OS 10.12 or higher
5 V (USB port)
110x35mm
175x140x110mm
- 30 -
