I N T R O D U C T I O N
1

Introduction

Thank you from all of us at ProMariner and congratulations on your recent purchase of the
ProTournament elite On-Board Marine Battery Charger.
The fastest charger with the most features in its class. Specifically designed to deliver maximum
charging performance and extend battery life. Get on the water first and stay there longer with
tournament winning technology providing: 100% charge upon completion of multi-stage charging
process. 100% charging output with AC power as low as 90 VAC. 50% lighter and 2 to 3 times faster
than traditional chargers.
Give your batteries what they demand with ProTournament elite's three (3) digitally selectable
"performance matched" 5-stage charge profiles. Using 100% of the available charging amps,
ProTournament elite 's Distributed-On-Demand ™
charging output to the combination of batteries connected to it as required by the discharge state
of each battery.
Have the edge with our elite Professional Performance feature set:
Forced Induction Cooling (360 elite models only)
For cooler operation and the fastest charge times
Digital LED Display with Dual Mode Battery Status Monitor
Intuitive LED display with charge mode indicators and real time charge level status with an
on-the-water push-to-test feature for percent of battery power remaining.
3 Selectable Performance Matched Charge Profiles
Profiles include: Standard Flooded/AGM batteries, HP AGM1 for pure lead AGM batteries like OPTIMA
Blue Top Marine Batteries, HP AGM 2 for pure lead AGM Batteries like Odyssey Marine Batteries.
Waterproof Connector Port for Optional Status Remote
Optional tri-color LED charge mode status remote can be placed up to 12' away from the charger.
Digital 5-Stage Charging with Temperature Compensation
Analyzes connections and the ability for a battery to accept a charge, advance high fill rate charging,
conditioning, auto maintain (energy saving mode) and automatic once a month storage recondition
mode automatically monitors ambient temperatures and adjusts its charging output.
System OK & Individual Battery Trouble Status Indicators
Advanced technology eliminates time consuming trouble shooting by clearly indicating system
and battery connections are OK or if a fault is present on a specific battery bank.
Built-in Safety and Pre-Wired for Easy Installation
Shock resistant, space saving extruded aluminum design, dual in-line DC safety fuses for
trolling motor and house batteries, over-voltage, overload, over-temperature, reverse polarity
and ignition protection.
3-Year Warranty
Charging technology will always distribute its full

Important Safety Instructions

SAVE THESE INSTRUCTIONS
This manual contains important safety and operating instructions for the ProTournament
elite On-Board Marine Battery Charger.
CAUTION - To reduce the risk of injury, charge only Lead-acid type rechargeable
batteries; Flooded, AGM, and High Performance AGM. Other types of batteries may
burst, causing personal injury.
Use of attachments not recommended or sold by ProMariner may result in a risk of fire,
electrical shock or personal injury.
EXTERNAL CONNECTIONS TO CHARGER SHALL COMPLY WITH THE UNITED STATES
COAST GUARD ELECTRICAL REGULATIONS (33CFR183, SUB PART 1).
Before connecting your batteries or applying AC power, read all instructions and cautionary
markings on the battery charger, cables, and batteries.
WARNING
To reduce the risk of injury to user or property; the user must read and understand the instruction
manual and all warnings on the charger and batteries before use.
WARNING
RISK OF EXPLOSIVE GAS MIXTURE. Read instructions in manual before using charger.
1. Connect and disconnect battery leads only when supply cord is disconnected.
2. Do not overcharge battery - See Instruction Manual.
3. Do not smoke, strike a match, or cause a spark in vicinity of battery.
4. Use in well-ventilated area.
5. Refer to Instruction Manual for further details.
CAUTION
Risk of Electric Shock. Connect only to properly grounded GFCI (ground fault circuit interrupt)
protected outlets.
Do not expose AC Power cord connection to rain or snow.
If cords or wires/cables become damaged return complete unit to ProMariner for service/repair immediatel y .
WARNING
1. WARNING - RISK OF EXPLOSIVE GASES.
a. WORKING IN THE VICINITY OF A LEAD-ACID BATTERY IS DANGEROUS. BATTERIES
GENERATE EXPLOSIVE GASES DURING NORMAL BATTERY OPERATION. FOR THIS
REASON, IT IS OF UTMOST IMPORTANCE THAT YOU FOLLOW THE INSTRUCTIONS
EACH TIME YOU USE THE CHARGER.
b. To reduce risk of battery explosion, follow these instructions and those marked on the battery.
2. Use charger for charging a LEAD-ACID battery only. It is not intended to supply power to an
extra-low-voltage eletrical system or to charge dry-cell batteries. Charging dry-cell batteries
may burst and cause injury to persons and property.
3. NEVER smoke, strike a match or cause a spark or flame in vicinity of battery.
4. NEVER charge a frozen, damaged or leaking battery.
S A F E T Y I N S T R U C T I O N S
2
