Screw to switch from 3 to 4 stages

4. Technical features

MiniDive Pro (Pro+, Carbon, Carbon+, Carbon Max) :
-
Internal water volume of the tank : 0,5 L (0,8 L for the MiniDive Pro+, 0,48 L for the MiniDive Carbon, 1,1 L for the
MiniDive Carbon+, 2 L for the MiniDive Carbon Max)
-
Maximum authorised pressure (PS) : 200 bar (3000 PSI) for the MiniDive Pro and Pro+, 250 bar (3750 psi) for
the MiniDive Carbon, 300 bar (4500 PSI) for the MiniDive Carbon+ and Carbon Max
-
Service temperature : +10°C / +40°C (50°F / 104°F)
-
Weight : 2,1 kg (4,6 lbs) empty for MiniDive Pro, Carbon / 2,5 kg (5,5 lbs) empty for MiniDive Pro+, Carbon+ / 2,9 kg
(6,4 lbs) for MiniDive Carbon Max
-
Dimensions : 30,5x19x10 cm for MiniDive Pro / 34x19x10 cm for MiniDive Pro+ / 36x19x10 cm for MiniDive Carbon /
30x20x11 cm for MiniDive Carbon+ / 50x19x10 cm for MiniDive Carbon Max
-
Maximum authorised depth of use : 3 m (10 ft)
-
Maximum operational depth of the equipment (allowed for certified divers according to their scuba
certification) : 50 m (164 ft)
M4S pump :
-
Maximum pressure authorised : 200 bar (3000 PSI)
-
Dimensions (h x l) : 65 x 21 cm (2 x 0,7 ft)
-
Weight : 2 kg (4,4 lbs)
5. Precaution of general use
• Due to its vital fonction, always use it with care
• Never force on the valve
• When MiniDive Pro (Pro+, Carbon, Carbon+, Carbon Max) is not used, don't let the top compartment under
pressure, purge the air thanks it the second stage membrane
• Too much stress on the second stage membrane can engender a too important air expulsion, to stop it, obstruct the
mouthpiece
• Avoid any contact between sand or condiment and the MiniDive Pro (Pro+, Carbon, Carbon+, Carbon Max) and the
M4S hand pump
• Don't expose the material to the sun for a long time
• During the first use, connect the first stage regulator to the valve and make a complete test of the tank into the air to
evaluate your feeling
