Full Programming Options

Quickstart >
Accessories >
Alarm no.1
Tech.no.
Background no.
Volume
Location
ID Code
Network ID
Time
Date
Tel. Numbers >
Alarm no. 1
Alarm no. 2
Alarm no. 3
Alarm no. 4
Tech.no.
Background no.
Call attempts
Guided Voice Unit will play a Guidance
Message (see page 10) to the
call centre when answering an
alarm call
Unguided No message is played when a
Voice
alarm call is answered.
NOTE: If 'Auto Location' has
been selected in 'System
Config+' then the location
message WILL automatically
play at the start of the call.
Memco
Protocol required if receiving
background test calls with the
Avire Hub or ETR.
P100 Protocol required if receiving
background test calls in the
Avire Hub. Can also be used
with other P100 compatible
software.
Contact ID Protocol required if receiving
background test calls with
'Contact ID' receiver software
Fig. 1
Menu Sections
Quick Start
The quick start menu consists of 8 menu options required for quick setup.
Please refer to the previous page in this guide for more information.
Menu Sections
Tel. Numbers
Alarm no.
Up to four alarm telephone numbers can be programmed in the Memcom
unit.
Using the keypad, enter the first alarm telephone number.
When using a Hotline, enter the telephone number as 0. This is only required
if the Hotline option has not already been set in System Config+, otherwise
the menu automatically displays the protocol list without the need to enter
any number.
Select a protocol required from Fig 1 (on the left), scroll to the preferred
protocol and press # to confirm.
Note: When connecting to a PBX/PABX, insert the number required to get
an outside line, followed by a pause (*), followed by the telephone number.
i.e.. 9*01344854000
If further alarm numbers are required, repeat this process for each alarm.
Tech. no.
The Memcom can place Technical alert calls to signal faults with the system.
+
A Technical alert is a non-scheduled event e.g. from a Technical Input or low
battery with no main power.
All other diagnostics are checked during a scheduled Background Call (see
below). As standard this number is attempted the number of times indicated
by the 5th digit in Call Attempts (see below Call Attempts) screen before
waiting for the next technical alarm. If using the Avire Hub, set Tech no. to
03308088484 and select the P100 protocol. Use Memco protocol when
connecting via any other type of GSM or a landline.
Background no.
To set up the EN81-28 three day test call (background test call) programme
the required telephone number here. If using the Avire Hub, set Background
no. to 03308088484 and select the P100 protocol. Use Memco protocol
when connecting via any other type of GSM or a landline.
Call Attempts
The number of attempts the Memcom
number (maximum is 9 attempts per number). The default is '999999'; each
digit identifies one of the six programmed telephone numbers.
+ will make to contact each telephone
+
7 7
